Oldal 1/13
H O M E A U D I O • C A M B R I D G E
Si
erra Plus
Dolby Atmos soundbar with wireless subwoofer
User Manual
EN
4
Preparation for use
Unpacking and installation
• Remove t
he audio bar from the package and remove all packing material from the audio bar. Save the
packing material, if possible, in case the audio bar needs to be serviced or transported. The original carton
and packing material is the only safe way to pack the audio bar and protect it from damage during
transport.
• Remove a
ny descriptive labels or stickers on the front or top of the cabinet. Do not remove any labels or
stickers on the back or bottom of the cabinet.
• Place the audio bar on a flat surface such as a table, desk, or shelf, near a power outlet, out of direct
sunlight, and away from sources of excessive heat, dirt, dust, moisture, or vibration.
• Unwind the lin
e cord connecting the AC adapter and extend it to its full length.
Protect furniture
This model is equipped with non-slip rubber feet to prevent the product from moving when operating the
controls. These feet are made of non-migrating rubber material specially formulated to avoid leaving marks or
stains on furniture. However, some types of oil-based furniture polishes, wood preservatives or cleaning sprays
may cause the rubber feet to soften and leave marks or rubber residue on the furniture. To avoid damaging
your furniture, we recommend that you purchase small self-adhesive felt pads, available at hardware stores
and home centers, and apply them to the base of the rubber “feet” before placing the unit.
Power Source
• This s
ound bar is designed to operate on 110V -240V ~ 50Hz/60HzImportant Notes
• Safety a
nd operating instructions should be kept for future reference.
• The d
evice should not be exposed to drops, splashes or placed in a humid atmosphere. such as a
bathroom.
• Do not install the product in the following areas:
• Places e
xposed to direct sunlight or near radiators.
• Above o
ther stereo equipment that radiates too much heat - Blocking ventilation or in a dusty area.
• Areas s
ubject to constant vibration.
• Damp o
r wet places.
• Do no
t place near candles or other flames.
• Use the pr
oduct only as instructed in this manual.
• Before t
urning on the device for the first time, make sure the soundbar is plugged into the power outlet.
• For s
afety reasons, do not remove the covers or attempt to access the inside of the unit.product. Refer any
maintenance work to qualified personnel.
• Do not attempt to remove screws or open the unit casing; there are no user screws. serviceable parts
inside. Refer to qualified personnel for maintenance.
Preparation for use
EN
5
.
4
1. LED Subwoofer indicator: Indicates pairing between the soundbar and
subwoofer. (Make sure the soundbar and subwoofer are connected to the
power supply at the same time, and then turn on the soundbar and
subwoofer).
2. PAIR button: Automatically pairs the soundbar with the subwoofer.
Holding it down resets the connection between the sound bar and
subwoofer.
3. USB port (cannot play MP3 music, FOR SOFTWARE UPDATING ONLY)
4. AC IN (Connect to power supply).
COPPI
A
COPPIA
Product Diagram
1
2
3
4
5
6
USB PORT: Audio input from a USB storage device. Update the
software for this product.
OPTICAL: Connect to an optical audio output on TV or digital devices.
AUX: Auxiliary Audio input from Mp3/Phone/set-top box devices.
HDMI OUT (ARC): Connect to HDMI (ARC)/HDMI IN on TV.
HDMI IN 1 : Connect to HDMI OUT of TV/Satellite/ Network/.Set-top
box/BD/Blue Ray DVD/DVD player.
HDMI IN 2 : Connect to HDMI OUT of TV/Satellite/Network/Set-top
box/BD/Blue Ray DVD/DVD player.
AC IN: Connect the power supply to power .
INPUT: Select an input source for the Soundbar.
Volume: Increases the volume.
Volume: Reduces the volume.
Standby-on: Turns on or puts the Soundbar on standby.
DISPLAY PANEL.
7
8
9
10
11
12
