Oldal 1/14
Instruction Manual
Puck Pro Dive Computer
Puck Pro Dive Computer
2
• TABLE OF CONTENTS
1 INTRODUCTION 3
1.1 GLOSSARY 3
1.2 OPERATING MODES 4
1.3 USERREPLACEABLE BATTERY 4
1.4 CONNECTING PUCK PRO TO A PC OR MAC 4
1.5 BUTTON OPERATION 4
2 MENUS, SETTINGS AND FUNCTIONS 6
2.1 MODE 6
2.2 SET 6
2.2.1 SET DIVE 7
2.2.1.1 LGHT BACKLIGHT 7
2.2.1.2 P P FCT P FACTOR 7
2.2.1.3 ALT ALTITUDE 7
2.2.1.4 WATR WATER 7
2.2.1.5 UN:TS UNITS 7
2.2.1.6 FAST FAST ASCENT 7
2.2.1.7 ALRM ALARMS 8
2.2.1.8 ERASE ERASE DESATURATION 8
2.2.2 SET TIME 8
2.3 LOGBOOK 8
2.4 DIVE PLANNER 8
2.5 PC 8
2.6 INFO 8
3 DIVING WITH PUCK PRO 8
3.1 A FEW WORDS ABOUT NITROX 8
3.2 ALARMS 9
3.2.1 ASCENT RATE 9
3.2.2 MOD/PPO
2
9
3.2.3 CNS = 100% 9
3.2.4 MISSED DECOMPRESSION STOP 9
3.2.4.1 MISSED DECO STOP MODE 10
3.2.5 LOW BATTERY 10
3.3 DISPLAY INFORMATION 10
3.4 AFTER THE DIVE 10
3.5 DIVING WITH MORE THAN ONE GAS MIXTURE 11
3.5.1 SETTING MORE THAN ONE GAS 11
3.5.2 SWITCHING GAS 11
3.5.3 SPECIAL SITUATIONS 12
3.5.3.1 SWITCHING BACK TO A GAS MIXTURE WITH
LOWER OXYGEN CONCENTRATION 12
3.5.3.2 SUBMERGING BELOW THE MOD AFTER A GAS
SWITCH 12
3.6 BOTTOM TIMER MODE 12
3.6.1 DIVE VIOLATION INDUCED BOTTOM TIMER MODE 12
4 TAKING CARE OF PUCK PRO 12
4.1 TECHNICAL INFORMATION 12
4.2 MAINTENANCE 12
4.2.1 REPLACING THE BATTERY IN PUCK PRO 12
4.3 WARRANTY 13
4.4 WARRANTY EXCLUSIONS 13
4.5 HOW TO FIND THE PRODUCT SERIAL NUMBER 13
5 DISPOSAL OF THE DEVICE 13
3
• 1 INTrOduCTION
1.1 gLOSSAry
:
Symbolizes uncontrolled ascent violation.
:
Symbolizes decompression stop violation.
ASC:
Total ascent time, the time it takes to perform the ascent from your current
depth to the surface in a decompression dive, including all decompression
stops and assuming an ascent rate of 10m/min or 33ft/min.
AVG: Average depth, calculated from the beginning of the dive.
CNS: Central Nervous System. CNS% is used to quantify toxic effects of oxygen.
DESAT:
Desaturation time. The time needed for the body to eliminate the nitrogen
taken up during diving.
Gas switching: The act of changing from one breathing gas to another.
Max depth: Maximum depth attained during the dive.
(MOD):
Maximum Operating Depth. This is the depth at which the partial pressure
of oxygen (ppO
2
) reaches the maximum allowed level (ppO
2
max). Diving
deeper than the MOD will expose the diver to unsafe ppO
2
levels.
Multigas:
Refers to a dive in which more than one breathing gas is used (air and/or
Nitrox).
Nitrox:
A breathing mix made of oxygen and nitrogen, with the oxygen
concentration being 22% or higher.
NO FLY /
:
Minimum amount of time the diver should wait before taking a plane.
No deco time:
This is the time that you can stay at the current depth and still make
a direct ascent to the surface without having to perform mandatory
decompression stops.
O
2
: Oxygen.
O
2
%: Oxygen concentration used by the computer in all calculations.
P Factor:
Personalization factors, which allow the user to select between the
standard decompression algorithm (P0) and an increasingly more
conservative one (P1, P2).
ppO
2
:
Partial pressure of oxygen. This is the pressure of the oxygen in the
breathing mix. It is a function of depth and oxygen concentration. A ppO
2
higher than 1.6bar is considered dangerous.
ppO
2
max:
The maximum allowed value for ppO
2
. Together with the oxygen
concentration it defines the MOD.
Switch depth:
The depth at which the diver plans to switch to a higher oxygen
concentration mix while using the multigas option.
S.I.: Surface interval.
