Exterior Dot-1/4/9 Pro

User Manual

with Safety and Installation Manual

Exterior Dot-1 Pro

Exterior Dot-4 Pro

Exterior Dot-9 Pro

Notes

appearance are subject to change without notice. HARMAN PROFESSIONAL DENMARK ApS and all

affiliated companies disclaim liability for any injury, damage, direct or indirect loss, consequential or

economic loss or any other loss occasioned by the use of, inability to use or reliance on the

information contained in this document. Martin is a registered trademark of HARMAN

PROFESSIONAL DENMARK ApS registered in the United States and/or other countries.

HARMAN PROFESSIONAL DENMARK ApS, Olof Palmes Allé 44, 8200 Aarhus N, Denmark

HARMAN PROFESSIONAL, INC., 8500 Balboa Blvd., Northridge CA 91325, USA

www.martin.com

Exterior Dot-1/4/9 Pro User Manual English, Revision A



Table of contents

Notes .................................................................................................................... 2
Introduction .......................................................................................................... 4
Optional accessories ............................................................................... 4
Before using the product for the first time ............................................... 4
System installation ............................................................................................... 5
System setup ....................................................................................................... 8
Setting up for P3 display ......................................................................... 8
Setting up for DMX control ...................................................................... 8
Setting up via RDM ................................................................................. 9
Device information ................................................................................ 10
Setting DMX mode ................................................................................ 11
Setting DMX addresses ........................................................................ 11
Dimming curves .................................................................................... 11
Pixel flip mode ....................................................................................... 12
Standalone operation ............................................................................ 12
Behavior when no DMX signal is present ............................................. 12
Power limit mode ................................................................................... 12
LED refresh modes ............................................................................... 12
Color modes .......................................................................................... 12
CTC ....................................................................................................... 13
Tint ........................................................................................................ 13
Dot string length .................................................................................... 13
Utilities ................................................................................................... 13
Using the Exterior Dot-1/4/9 Pro ........................................................................ 14
Temperature precautions and thermal regulation ................................. 14
Power up confirmation flash .................................................................. 14
P3 display .............................................................................................. 14
DMX control .......................................................................................... 14
Standalone operation ............................................................................ 15
FX .......................................................................................................... 17
Maintenance ....................................................................................................... 19
Cleaning ................................................................................................ 19
DMX Protocols ................................................................................................... 20
Standard Mode ...................................................................................... 21
Extended Mode ..................................................................................... 21
Raw Mode ............................................................................................. 24
RGB Mode............................................................................................. 24
PixelMap Mode ..................................................................................... 24
FX list .................................................................................................... 25
Specifications ..................................................................................................... 40
