Power over Ethernet AF/AT PowerView Pro User Guide

Introduction

This User Guide introduces Microchip’s IPv6 capable Power View Pro Remote Web Managers used for managing

Microchip’s Power over Ethernet (PoE) product line of IPv6 capable Midspan devices including:

•10/100Mbit Midspans

–PD–6506/AC/M: 6 port 10 Mbit/100 Mbit Midspan

–PD–6512/AC/M: 12 port 10 Mbit/100 Mbit Midspan

–PD–6524/AC/M: 24 port 10 Mbit/100 Mbit Midspan

–PD–6524/AC/M/F: 24 port 10 Mbit/100 Mbit full power Midspan

Note:  Only Network Management Modules with internal FLASH memory of 4MB can be upgraded to latest IPv6

complient software version. For further information, see 6.2 Midspan Manager Module Software Upgrade .

•1 Gigabit Midspans

–PD – 6506G/AC/M: 6 port 1 Gigabit Midspan

–PD – 6512G/AC/M: 12 port 1 Gigabit Midspan

–PD – 6524G/AC/M: 24 port 1 Gigabit Midspan

–PD – 6524G/AC/M/F: 24 port 1Gigabit full power Midspan

•1 Gigabit High Power 802.3at compliant Midspans

–PD – 9006G/ACDC/M: 6-port High Power 1 Gigabit 802.3at compliant Midspan

–PD – 9012G/ACDC/M: 12-port High Power 1 Gigabit 802.3at compliant Midspan

–PD – 9024G/ACDC/M: 24-port High Power 1 Gigabit 802.3at compliant Midspan

–PD – 9024G/ACDC/M/F: 24-port Full High Power 1Gigabit 802.3at compliant Midspan

•1 Gigabit High Power 802.3at compliant four-pair Midspans

–PD – 9506G/ACDC/M: 6-port High Power 1 Gigabit 802.3at compliant four-pair Midspan

–PD – 9512G/ACDC/M: 12-port High Power 1 Gigabit 802.3at compliant four-pair Midspan

–PD – 9524G/ACDC/M: 24-port High Power 1 Gigabit 802.3at compliant four-pair Midspan

•1 Gigabit High Power 802.3at compliant energy efficient Midspans

–PD – 5524G/ACDC/M: 24-port High Power 1 Gigabit 802.3at compliant energy efficient Midspan

•1 Gigabit High Power PoH compliant four-pair Midspans

–PD – 9606G/ACDC/M: 6-port High Power 1 Gigabit PoH compliant four-pair Midspan

–PD – 9612G/ACDC/M: 12-port High Power 1 Gigabit PoH compliant four-pair Midspan

This guide is intended for network administrators, supervisors, and installation technicians who have a background in

the following domains:

•Basic concepts and terminology of networking

•Network topology

•Protocols

•Microsoft Windows environment

© 2021 Microchip Technology Inc.

and its subsidiaries

User Guide

DS00003988A-page 1
