EN - English -Quick Guide:

This Quick Guide covers the model: L41G-2axD.

This is a wireless network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most relevant technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, brochures, and more info about products are at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

If you need help with configuration, please seek a consultanthttps://mikrotik.com/consultants

First steps:

;Ensure your Internet Service Provider (ISP) allows hardware changes and automatically assigns an IP address

Connect the ISP cable to the Ethernet1 port;

Connect the device to the power source;

Connect to the device through any of the ports, excluding Ethernet1, or the wireless network "MikroTik-..." (ensure to check the wireless passwords on the

sticker);multiple configuration methods are available to ensure accessibility;

Establish a connection using a mobile application.Alternatively, use WebFig in a web browser or the "WinBox" configuration tool at ;https://mt.lv/WinBox

Start configuration within the chosen tool, using the default IP address 192.168.88.1. If the IP address is unavailable, use WinBox and choose the "Neighbors"

tab to find the device;

Proceed to connect using the MAC address. The username is "admin", and there is no password (or, for some models, check user and wireless passwords on

the sticker);

Click the "Check for updates" button and update RouterOS to the latest version;

For a manual update of the device, visit , select your model, and locate the required packages in the "Downloads" section;mikrotik.com

Upload downloaded packages to the WebFig or WinBox "Files" menu and reboot the device;

By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;

In the "QuickSet" menu set up the following: Choose your country, to apply country regulation settings;

Set up your wireless network password in the left field;

Set up your router password in the bottom field.

This device needs to be upgraded to RouterOS v7.7 or the latest stable version, to ensure compliance with local authority regulations!
