NEW MIOPS Splash User Manual
Content:
1. Content of the Package
2. Power and Operation
3. First Use
4. Camera and Flash Connection
5. Mobile Application
6. Connecting to MIOPS Splash
7. Firmware Upgrade
8. Using the Mobile Application
9. Adjusting Parameters
9.1 1st Drop
9.2 2nd Drop
9.3 Trigger
9.4 Auto Adjustment
10. Example Setup
11. Settings Screen
12. Valve Cleaning
13. Troubleshooting
1. Content of the Package
When you purchase a NEW MIOPS Splash Water Drop Kit, it will be delivered with
the following items.
1 x MIOPS Splash
1 x MIOPS Splash Holder (11” articulating arm)
1 x USB Power Cable
1 x Flash Cable (3.5mm to PC SYNC)
2. Power and Operation
Your MIOPS Splash comes with Micro USB power cable so you can attach it to any
USB power source to turn it on. When you attach your MIOPS Splash to any USB
power source, the LED will blink with short intervals which means it is waiting for
pairing with Miops Mobile app.
3. First Use
Your MIOPS Splash may not be delivered with the latest firmware. If a new
firmware has been released, before you have used it for the first time, you should
update the firmware first. To get detailed information about the firmware
upgrade, see the Firmware Upgrade Section.
4. Camera and Flash Connection
The MIOPS Splash uses connection cables to trigger your camera or flash unit. It can
trigger both of them but MIOPS Splash will be shipped with a flash cable only.
If you need to trigger your camera, you should purchase a camera connection cable
which is compatible with your camera brand and model. The MIOPS Splash is a
versatile device, which is compatible with many brand and models. You can use the
same device with many different cameras by just changing the camera connection
cable.
The MIOPS Splash has separate outputs for the camera and flash cables. The
Camera output is a 2.5 mm stereo female jack. The camera cables have the male
2.5 mm stereo jack on one end. This end is plugged into the camera output. The
other end changes depending on the camera make and model. This end is plugged
in the shutter release port of your camera.
The Flash output is a 3.5 mm stereo female jack. PC Sync Flash cable has a 3.5 mm
male jack on one end. This end is plugged into the Flash output. The other end of
the cable is a standard PC Sync port. This end is connected to the PC Sync port of
the flash unit. If your flash does not have a PC Sync port, you can use an hot shoe
adapter with a PC Sync port.
The camera and flash cables are designed to trigger the cameras and flash units
only. Do not use them for any other purpose. Doing so may damage the cable or the
device.
5. Mobile Application
MIOPS Splash requires a mobile app which has been designed as an interface to
configure and control your device easily. The communication between the
smartphone and MIOPS Splash is done over Bluetooth connection. So, your
smartphone has to be compatible with Bluetooth 4.0.
MIOPS MOBILE app is available on iOS and Android platforms. Search for MIOPS
MOBILE in your app store, or use the following buttons to download the app.
6. Connecting to MIOPS Splash
After opening the MIOPS Mobile app, it will search for available MIOPS products. If
you powered on your MIOPS Splash, you will see it on the app screen as below.
Just touch the orange button at the right bottom corner to complete the pairing.
Once pairing is completed, MIOPS Splash setup screen will appear on the screen.
