Oldal 1/8
iX2
Owner’s manual
Thank you for choosing MTX iX2+
high definition earphones. The
iX2+ are designed to add a deeper
dimension and bring your music to
life. Wherever you are, the iX2+ will
deliver phenomenal sound quality
with a Pullman comfort. The iX2+
are the earphones you’ll never forget.
Congratulations for making the right
choice. Enjoy the ultimate audio
experience with MTX.
USA - UK
User Interface User Interface
Active noise canceling menu
= =
Power on
Bluetooth Pairing
Ear tips
Quick StartIn the boxSpecifications
Charging box dimensions
Charging box LED behaviour
Earphones LED behaviour
1
3
2
Controls on the earphones
Charging
• Multipoint Bluetooth 5.3 wireless earphones
• Hybrid Active Noise Cancelling with 6 mics
• Qualcomm
®
aptX
™
Adaptive BT top level chips
• Noise reduction up to -38dB @ 200Hz
• Bluetooth codecs : Adaptive aptX, aptX, AAC, SBC
• Bluetooth profiles : A2DP1.3, AVRCP1.6, HFP1.7,
SPP1.2, GATT
• Bluetooth range : ~10 meters
• Weight : case 65g, earphones 2x 3.5g
• Battery : 50mA in each earphone
• Battery : 450mA in the charging case
• Recharge : USB-C, 5V DC, 700mA
• USB-A to USB-C charging cable included
• Listening time : up to 7 hours per charge
• Speakers : Ø10mm wide range Peek/TPU cone
• IPX4 water resistant
• Zinc charging case
• Silicon eartips : 4 sizes included
• LED charging indicator (case + earphones)
• The two iX2+ earphones
• The iX2+ charging case
• The USB-A to USB-C charging cable
• This owner’s manual
50mm 21.5mm
49mm
1x
1x
1x
2x
3x
2x
Calls
Power
(The iX2+ will automatically shut down after 5 min
without any Bluetooth connection)
Reject Reject
Music
Noise cancelling
Noise cancelling mode
Use it when travelling on a
plane, train, car, road, etc.
External noise is reduced by
up to -38dB @200Hz.
Music mode
All the active
noise Cancelling
circuits are
switched off for
maximum sound
quality.
Transparency mode
Use this mode when you want to hear what's
going on around you. The sounds around you
are injected into the earphones to compensate
for the natural isolation of silicone-tipped
earphones. Use it when you want to hear
perfectly someone talking to you, or when you're
walking down the street.
Search for "MTX iX2+" in your device's
Bluetooth list and connect. You should hear
"Connected" in your iX2+.
Bluetooth device name : "MTX iX2+"
Remove the iX2+ earphones from their charging box. If
the iX2+ is not yet paired, it will say "Pairing" and it will
be visible by any Bluetooth device. If the iX2+ is already
paired, you'll hear "Connected".
1dB/sec
5sec
ON/OFF ON/OFF
Left Left
USB-C charging port
Charging LED
Right Right
Touch the control surface Touch the control surface
S M L XL
Try different sizes of ear tips to make sure they
fit your ears perfectly. Bass response is greatly
affected by leaky ear tips.
• When battery is low : LED flashing red @1Hz
• When charging : from 0 to 33% LED pulsing red, 33~66% pulsing yellow, 66~100% pulsing green
• When charging box recharged : LED off
• When charging the earphones : from 0 to 33% LED red 8s., 33~66% yellow 8s., 66~100% LED green 8s.
• When earphones recharged : LED off
• When Bluetooth is disconnected = pairing mode : Flashing white @1Hz
• When Bluetooth pairing is successful : Solid red during 2 seconds
• When battery is low : Flashing red every 4 seconds
• When charging : Solid red
• When recharged : LED off
• When reset : Solid red and white during 1 second, then off
• When Power ON : Solid white during 2 seconds
Hybrid Active Noise Cancelling
Wireless Earphones
Designed by MTX
in Phoenix, AZ - USA
5x
Reset Reset
Reset
(To reset, the iX2+ must be disconnected from any device)
L R
Touch control
surface
Active Noise
Cancelling mics
Active Noise
Cancelling
and voice
capture mics
LED
Left
earphone
Right
earphone
