HDMI 1X2 Splitter, UHD- 4K
500423
Overview:
The HDMI 1x2 Splitter (500423) allows one (1)
HDMI source to be distributed to up to two (2)
HDMI displays. The splitter supports up to 4K
(3840 X 2160), 8 bit color and HD audio. The -
splitter is HDCP 1.3 compliant and features LED
diagnostics. Additionally, all HDMI connectors
are on the rear panel for neater cabling.
Applications include; commercial and residential
AV systems, classroom projector systems, digital
signage, boardroom systems, collaborative PC
systems, medical information systems.
Applications:
Commercial and residential AV systems
Classroom training systems
Digital signage
Boardroom systems
Medical video systems
Key Features:
• Distribute one HDMI source to two displays
• Support up to 1080p @ 60Hz, Deep Color 12-
b it
• Support 2K and 4K resolutions
• Support Dolby TrueHD and DTS-HD Master
Audio
• Support 3D
• LED diagnostic
• HDMI 1.4
• HDCP 1.3 compliant
Environment
HDMI 1.4 (3D)
Devices
DVD/Blu- s Ray, plasma, projectors, monitors, TV, PC, laptop
Transmission
Transparent to the user
Frequency
25 to 340 MHz
Signals
HDMI 1.4 protocol
Connectors
HDMI receptacle.
LEDs
Power: Green
Input & Output Link: Blue
Resolution
480i to 1080p @ 50/60 FPS
1080p @ 24/50/60 FPS
3840 X 2160 @ 24/25/30 FPS
VGA to UXGA
Color
8, 10 & 12 bit
Audio
LPCM 7.1CH, Dolby TrueHD and DTS HD Master Audio-
HDCP
Revision 1.3
Cable
HDMI Cable
Temperature
Operating: 0° to 40°C 20° to 60°C Storage: -
Humidity: up to 90% non-condensing
Enclosure
Metal enclosure
Dimensions
3 .50” x 2.00” x 1.00” 89 mm x 51 mm x 25 mm)
Weight
0.8 lbs (0.36 Kg)
Compliance
Regulatory: FCC, CE, RoHS
Warranty
2 years
Order Information
500423 HDMI 1X2 Splitter, UHD 4K (UPC: 627699004234)-
© MuxLab Inc. 2014 -HDMI 1x2 Splitter, UHD 4K

HDMI 1x2 Splitter, UHD- 4K
500423
__________________________________________________________________________________
Typical Application
© MuxLab Inc. 2014 HDMI 1x2 Splitte r, UHD-4K
MuxLab Inc.
8495 Dalton Road, Mount Royal, Quebec, Canada, H4T 1V5
Tel: (514) 905 0588 Fax: (514) 905 0589
Toll Free:1 877 689-5228
E-mail: videoease@muxlab.com
www.muxlab.com
