Intel SDM based

HDBaseT 4K/UHD Receiver

USER MANUAL

SDM--R- HDBTUHD

USER MANUAL v.1.4

Overview

The SDM-HDBT-R--UHD can be installed in any display that is equipped with Intel SDMS

or SDM- -L slot.The SDMHDBT-R-UHD uses HDBaseT™, it is compatible ntac with Apa

HDBT-1-E- UHDtransmitters and can extend 1080P HDMI signal up to 100/150 meters

and 4K/UHD HDMI signals up to 70 meters.

Package Contents

§1 x SDM-HDBT-R- UHD

§1 x User manual

§1 x SDMS mounting bracket-

§1 x SDM-L mounting bracket

§1 x IR receiver

§1 x IR blaster

Features

nSupports 4K@60Hz (4:4:4up to 100 meters with CAT6a) /CAT7 cables

nSupports 4K@60Hz (4:2:0) 1080P (12bit) and 3D up to 100 metersand

nSupports HDMI 2.0

nSupports HDCP 1.4 and 2.2

nSupports 3D pass- through

nSupports CEC passugh-thro

nSupports RSdirectional)--232 (Bi

nSupports all frequency of IR control

nSupports HDBaseT Mode with Apantac H DBaseT Transmitter

nSupports all digital audio meter modes

nSupports P@60Hz / 8bitLong Reach Mode (0108, up to 150 meters)with Apantac

HDBaseT Transmitter

Specifications

Function

SDM-HDBT-R- UHD

SDM Edge Connector

Intel SDM PCIex8(98pin) x1

HDBaseT Link In

RJ45x1

IR In

3.5ψ Stereo Jack x 1

IR Out

3.5ψ Stereo Jack x 1

St atus LEDs

4 in 1 LED

Max Resolution

4K@60Hz (4:4:4/4:2:0), 4K@30Hz, 1080P@60Hz

Cable distance

100 m for 4K@60Hz(4:4:4)with CAT6a/CAT7 cables,

10 00/150m for 1080P@6Hz

Mounting Brackets

SDM--L S, SDM

Weight

Board - -– -– 60g, SDMS 80g, SDML 160g

Dimensions (LxWxH)

Board --60x110x20, SDMS – -L – 80x124x25, SDM

195x124x25 mm
