Oldal 1/5
4G LTE Cat 6
Industrial IoT Router with Dual Band WiFi
Model # NTC-400 Series
KEY BENEFITS
IMPROVED CONNECTIVITY
The NTC-400 supports 4G LTE Cat 6 to deliver the highest
speed possible. External antennas with high gain reception
make the device ideal for installation at the fringe of the
network. The high-speed dual band WiFi and integrated hotspot
functionality allow the NTC-400 to provide public Internet access
when necessary.
CONFIGURABLE POWER MANAGEMENT SCHEME
Ignition sensing interface and timer-based activation are ideal
for vehicular and power constrained environments, allowing the
NTC-400 to wake up only when needed, complete the required
process and return to low power sleep mode.
REMOTE MANAGEMENT
Supporting industry leading protocols, the NTC-400 is easy
to integrate into the existing remote management platform.
A built-in event notication, remote conguration and
troubleshooting via SMS makes it faster and easier to manage
a large eet of devices.
ENHANCED RELIABILITY
To endure harsh industrial and automotive environments, the
NTC-400 features a robust enclosure made from steel and
extruded aluminium. Electrical components have been carefully
selected to allow the device to operate at extreme temperatures
for many years without fail.
The NetComm 4G LTE Cat 6 Industrial IoT Router with Dual
Band WiFi (NTC-400) creates high speed and reliable data
connectivity where xed line connections are either unavailable or
not suitable for the application. The NTC-400 creates high speed
dual band WiFi hotspots in public transport, streams HD video
from multiple surveillance cameras simultaneously, tracks vehicles
using GPS, and supports countless other bandwidth-intensive IIoT
applications in real time.
www.netcommwireless.com
APPLICATIONS
• Surveillance cameras
• WiFi in a bus
• Smart eet tracking
• Digital signs
• Network fringe installation
• Business continuity for point of sales systems
• Temporary ofces
KEY FEATURES
• Cat 6 4G LTE (300 Mbps) and dual band Wi-Fi for high
speed applications
• Dual SIM functionality for network redundancy
• Three Gigabit Ethernet ports, a serial port, and a USB port
for network exibility
• Integrated GPS compatible with all global systems for
reliable tracking applications
• I/O ports to read sensors or remotely control equipment
such as lights, fans or pumps
• Rugged industrial design with a metal housing and a wide
temperature rating for harsh environments
• Ignition sense capability and a wide input voltage range for
vehicular application
www.netcommwireless.com
Device Features
NTC-400 Series
WHAT’S IN THE BOX
OPTIONAL ACCESSORIES
USB portStatus LEDs
SIM card
slot A
Reset
button
Gigabit Ethernet
WAN/LAN port
Gigabit Ethernet
LAN ports
GPS
connector
8-way terminal
connector
(power, ignition input, I/Os)
Wi-Fi antenna
connectors
Cellular connectors
1 x NetComm Wireless NTC-400 Series Router
2 x Wall mounting
brackets
1 x 8-way terminal
connector
2 x Wi-Fi antennas
4 x Wall mounting
bracket screws 1 x Quick start guide
2 x Cellular antennas
12V DC Power Supply
PSU-0060
SPECIFICATIONS
• International Efciency Level VI Power supply
• No-Load Power Consumption: 0.1 W (115 VAC 60 Hz)
• Average Efciency in Active Mode: 85% (115VAC 60Hz)
• Maximum input voltage range: 90 - 264 V AC (100 - 240 V AC Normal)
• Maximum input frequency range: 47 - 63 Hz (50/60 Hz Normal)
• Output voltage range: 11.4 - 12.6 V DC (Typical 12 V DC)
• Maximum output current: 1.5 A
• Maximum ripple and noise: 150 mV peak to peak
• Maximum output overshoot: 10%
• Protection against Over-Voltage, Over-Current and Short-Circuit
• Temperature range: 0°C - 40°C (Operating), -30°C - 70°C (Storage)
• Relative humidity range: 10% - 90%
• Altitude range: Sea level to 2,000 m
• Suitable regions: US/UK/EU/AU/SA/TW/CH/JP
• Safety certications: UL60950-1, CSA C22.2 NO.60950-1, EN60950-1,
AS/NZS 60950, GB4943, J60950, IEC 60950-1
• Lead length: 1.5 m
GPS Active
Patch Antenna
ANT-0038
SPECIFICATIONS
• Frequency range: 1575.42 MHz
• Gain: 28 dBi (GPS)
• VSWR: 1.92:1 MAX
• Polarization: R.H.C.P.
• Cable: RG174
• Cable length: 3 m
• Impedance: 50 Ω
• Voltage: 3.3-5.5 V
• Connector: SMA male
• Radome colour: Black
• Radome material: ABS
www.netcommwireless.com
Technical Specications
NTC-400 Series
CELLULAR BANDS
• LTE Bands:
– Band 1 (2100 MHz)
– Band 3 (1800 MHz)
– Band 5 (850 MHz)
– Band 7 (2600 MHz)
– Band 8 (900 MHz)
– Band 18 (850 MHz)
– Band 19 (850 MHz)
– Band 21 (1500 MHz)
– Band 28 (700 MHz)
– Band 38 (2600 MHz)
– Band 39 (1900 MHz)
– Band 40 (2300 MHz)
– Band 41 (2500 MHz)
• WCDMA Bands:
– Band 1 (2100 MHz)
– Band 5 (850 MHz)
– Band 6 (800 MHz)
– Band 8 (900 MHz)
– Band 9 (1700 MHz)
– Band 19 (800 MHz)
• TD-SCDMA Bands:
– Band 39 (1900 MHz)
CARRIER AGGREGATION COMBINATIONS
– Band 1 + 8/18/19/21
– Band 3 + 5/7/19/28
– Band 5 + 3/7
– Band 7 + 3/5/7/28
– Band 8 + 1
– Band 18 + 1
– Band 19 + 1/3/21
– Band 21 + 1/19
– Band 28 + 3/7
– Band 38 + 38
– Band 39 + 39
– Band 40 + 40
– Band 41 + 41
PEAK DATA SPEED
• 300 Mbps downlink
• 50 Mbps uplink
• LTE Category 6
ANTENNA CONNECTORS
• 2 x SMA connectors for 3G/4G antennas
• 1 x SMA connector for active GPS antenna
• 2 x Reverse SMA connectors for Wi-Fi antennas
ANTENNAS
• 2 x Dual band Wi-Fi antennas
– 3 dBi gain @ 2.4 GHz
– 5 dBi gain @ 5 GHz
INTERFACES
• 3 x 1000 Base-T Ethernet RJ45 port
– 1 x LAN/WAN port
– 2 x LAN ports
• Concurrent Dual Band Wi-Fi with 802.11n 2T2R (2.4 GHz)
and 802.11ac 2T2R (5 GHz)
• I/O terminal block providing:
– 1 x RS-232 Serial (TX and RX only) interface via I/O
terminal block
– 2 x Digital input
– 1 x Digital output
– 1 x Ignition sense
• 1 x USB portGPS
GPS
• GPS
• GLONASS
SIM CARD READER
• 1 x SIM card slot (NTC-402-01)
• 2 x SIM card slots (NTC-402-02)
WI-FI FUNCTIONS
• Wi-Fi Operation
– AP Router
– WDS
– WDS Hybrid Modes
• Wi-Fi Security
– WEP
– WPA
– WPA2
– WPA-PSK
– WPA2-PSK
– 802.1x
WAN FUNCTIONS
• 3G/4G WAN
• 3G/LTE IPv4, IP Passthrough
• Wi-Fi WAN
