Oldal 1/112
NORM
S UR FAC E MODE
DIVE M ODE
While at >10 FT (3 M) deeper
than 1/2 Max Depth after
Depths >80 FT (24 M).
NORM (Dive Main)
at 1/2 Max Depth for 2 min,
after Depths > 80 FT (24 M)
if Depth/Time set, after
Depths > 30 FT (9 M)
Button action, ALT access,
and Gas Switch items similar
to Main.
<
2s
S S S
A
Alarms
Aud AL
Depth AL
EDT AL
TLBG AL*
DTR AL*
PO2 AL*
FO2 Items*
FO2 Gas 1
FO2 Gas 2
DFLT
Utilities
Wet Act
Units
Deep Stop*
Safe Stop*
Algorithm*
Conserv*
BL Dura
Sampling
S
<
2s
O2%, FO2, PO2
2s
2s
2s
Time, Temp
Time, Temp
at 2 ft (0.6 M) for 1 sec
at 5 ft (1.5 M) for 5 sec
GAUGE
SURFACE MO DE
DIVE M ODE DIVE M ODE
FREE DIVE
SURFACE MO DE
at 2 ft (0.6 M) for 1 sec
at 5 ft (1.5 M) for 5 sec
at 2 ft (0.6 M) for 1 sec
at 5 ft (1.5 M) for 5 sec
Smartglo Smartglo Smartglo
Smartglo
SmartgloSmartglo
Press Press Press
M M M
<
2s
<
2s
<
2s
to SN
to SN
(Max Depth, EDT)
(Elev, Temp, Time)
Main Menu
Alt 1 (Last)
Alt 2
Fly
Log
Set A
Set U
Set M
Set T
History
SN
Items marked with * do not apply to the GAUG Menus
(Max Depth, EDT)
(Elev, Temp)
Main Menu
Alt 1 (Last)
Alt 2
CDT
Set FA
Set M
Deep Stop (No Deco) Safety Stop (No Deco)
Gas 1 Swch
Preview
Deep Stop
Preview
Gas 2 Swch
Preview
Swch To
Gas 1
Swch To
Gas 2
M
2s
M
2s
S
S
(if set for Run Timer)
GAUG (Dive Main) FREE (Dive Main)
ALT displays will auto
revert to Main in 5 sec if
A is not selected.
(Max Depth, EDT)
(Elev, Temp, Time)
(FO2, PO2)
Main Menu
Alt 1 (Last)
Alt 2
Alt 3
Fly/Dsat
Plan
Log
Set F
Set A
Set U
Set T
Set M
History
SN
Modes
NORM
GAUG
FREE
S
<
2s
<
2s
<
2s
<
2s
A A
Items similar to NORM.
to Set M
S
Alarms
EDT
DA1
DA2
DA3
2s
A
M
SS
2s2s
Start/Stop
Timer
Start/Stop
Timer
Add Timer
<
2s
<
2s
Reset
Timer
Reset
Timer
ack. Alarmsack. Alarms
A
M
<
2s
<
2s
Max Depth, EDT
(if Timer is on Main)
(if Run Timer is on Main)
ALT 1
ALT 2
To Main
CDT
2s
Time, Max Depth
A
<2s
A
<2s
A
<2s
A
<2s
A
<2s
A
<2s
To Main
<
2s
<
2s
AM
<
2s
S
Toggle
On/O
<
2s
S
Press
SS
PressPress
ALT 1
ALT 2
To Main
ALT 1
ALT 2
To Main
Will auto revert to Main in
5 sec if A is not pressed.
Will auto revert to Main in
10 sec if A is not pressed.
A
<
2s
M
<
2s
A
<
2s
M
<
2s
A
<
2s
M
<
2s
A hold - scrolls
through Menu items
2s
S
S
<
2s
2s
S
S
<
2s
2s
S
S
<
2s
2s
S
S
<
2s
2s
S
S
<
2s
I N N O V A T I O N F I R S T
Designed by Oceanic California
2002 Davis Street
San Leandro
California, 94577
USA
800-435-3483
www.oceanicworldwide.com
ISO 9001:2000 is a distinguished global
standard of quality management systems, not
only in design and manufacturing, but virtually
all aspects of company operations. Oceanic and
its family of companies are proud of their ISO
9001:2000 certication.
In European markets, certain product categories
are required to pass rigorous testing standards.
All Oceanic products that require testing have
surpassed the CE standards.
Oceanic products are covered by one or
more United States patents. Oceanic enforces
its patented technology actively and will
aggressively defend any infringement.
©2002 Design, 2009, All rights reserved.
Oceanic Worldwide
Doc. No. 12-5203-r02 (6/14/10)
ACTIVATION
Press and release any button. The display comes
full on displaying all segments then a countdown
sequence, then the Surface Main screen.
MAINTENANCE
(refer to the Reference section of the Operating Manual)
•
Rinse thoroughly with fresh water after activities
in salt water.
•
Annually >> take the VEO 3.0 to an Authorized
Oceanic Dealer for inspection.
•
Replace the Battery prior to dive trips and
vacations when multiples days of diving
are planned.
SPECIFICATIONS
(refer to the Technical Data section of the Operating Manual)
•
Max Operating Depth = 400 FT (120 M)
Depth Accuracy - +/- 1% full scale
•
Time Accuracy - +/- 1 second per day
•
Dive Mode - entered at 5 FT (1.5 M) for 5 seconds.
•
Post dive Surface Mode after 10 minutes on
surface following ascent to 2 FT (0.6 M) for
1 second.
•
Repetitive Dive - NORM (or GAUG) after 10 minute
post dive SI, FREE after 1 minute post dive SI.
•
Altitude Adjustments (of Ni-O2 calculations &
depth calibration) - begin at 3,001 feet (916
meters) elevation, continues up to max operating
elevation of 14,000 feet (4,270 meters).
•
Operating Temperature (in air) - 20 to 140 F
(- 6 to 60 C)
•
Operating Temperature (in water) - 28 to 95 F
(- 2 to 35 C)
Menu, step back
Advance, step forward
Select, save, light
•
<2s means quick press/release
•
2s means press/hold 2 seconds
•
Exit means escape (abort)
INCLUDED IN THE PACKAGE:
•
VEO 3.0, CR2450 Battery installed
•
CD (Operating Manual,
OceanLog PC Interface
Program and drivers)
•
Review Card
INCLUDED OR AVAILABLE
AS OPTIONS:
•
Lens Cover
Set T Menu
Date Format
Hour Format
Time
Date
A
<
2s
A
<
2s
A
<
2s
M
<
2s
M
<
2s
M
<
2s
Set Hour
S
<2s
Set Min
S
<2s
A
•
in Menu <2s or quick press - advances forward
through menu options. Hold - scrolls through items
•
in Set Routine <2s or quick press - increases the
value (or set point) of variable selected.
•
in dive mode - advances through alternate displays
S
•
in Menu <2s or quick press - accesses menu variable
•
in Menu 2s - steps back to previous selection
•
in Set Routine <2s or quick press - saves or accepts
menu variable (or set point).
M
•
in Menu <2s or quick press - moves back t
hrough menu options
•
in Set Routine <2s or quick press - decreases value
(or set point) of variable
•
in Menu or Set Routine 2s - exits current display and
returns to Main from any location in the data tree
SAMPLE MENUEU EUROPEAN UNION DIRECTIVES
•
The VEO 3.0 is in compliance with the
essential safety requirements of EU EMC
directive 89/336/EEC and PPE directive
89/686/EEC.
•
EU standards comformity certied by SGS
United Kingdom Ltd, Weston -
super - Mare, BS22 6WA, UK, Notied Body
No. 0120.
•
The VEO 3.0 is designed to comply with
EN13319:2000 Diving accessories - Depth
gauges and combined depth and time
measurement devices - Functional and safety
requirements, test methods. Any information
on decompression obligation displayed
by equipment covered by this standard is
explicitly excluded from its scope.
OCEANLOG PC INTERFACE
(refer to Reference section of the Operating Manual
and the Help section of the OceanLog program)
•
Dive data (i.e.; Max Depth, EDT, Gas, status)
can be downloaded from
VEO 3.0 memory*.
•
Settings (i.e.; Alarm, Utility, Time, Free
Mode) can be uploaded to the VEO 3.0,
veried, or downloaded from it.
•
VEO 3.0 rmware (operating system) can be
upgraded utilizing OceanLog.
•
Install OceanLog program and USB
driver, both on setup CD. Autoplay,
follow on screen instructions.
•
Create Personal Log le.
•
For OceanLog software updates visit
www.Oceanicworldwide.com
•
For OceanLog support call toll free
(866) 732-7877, 8 Am to 5 Pm
USA Pacic time.
PC REQUIREMENTS:
•
IBM®, or compatible, Personal Computer
with USB Port
•
Intel® Pentium 200 MHz or better
microprocessor
•
Microsoft® Windows® 98 Second Edition,
ME, NT, 2000, XP, or Vista
•
Super VGA card or compatible video
graphics adaptor (256 color or greater) with
a minimum 800 X 600 pixel screen area of
display settings
•
16MB of available RAM, 20MB of
available hard drive storage
•
Mouse, CD-Rom drive, Printer
*VEO 3.0 MEMORY CAPACITY 512K:
•
Less frequent data sampling rate (a VEO
3.0 Utility setting), allows more dives
(prole data) to be stored for download.
•
A 60 second sampling rate can retain
aproximately 100 dive hours of data, 30
sec approx. 50 hr, 15 sec approx. 25 hr, 2
sec approx. 4 hr, and 1 sec approx. 2 hr
of data.
POWER SUPPLY
(refer to Reference section of the Operating Manual)
•
VEO 3.0 - (1) 3 volt type CR2450 Lithium
Battery, 560 mAhr
•
Shelf Life - up to 5 years
•
Use Life -100 dive hours if (1) 1 hour dive
per day up to 300 dive hours if (3) 1 hour
dives per day
•
Replace the Battery prior to dive trips and
vacations when multiple days of diving are
planned.
•
Calculations and settings retained after
Battery replacement.
•
Dispose of battery according to local
regulations that apply to Lithium cells.
QUICK START GU
Read & Understand the Operating Ma
& Safety & Reference Manual
Descend,
Ascend,
or Stop
On
Gas
Low Batt
Log Mode
Depth id
Time or #
Deep Stop
is triggered
Surface Interval
Nitrox
Algorithm
Time id
Value is
Max Depth
Value is
PO2 (ATA)
Temp
Value is FO2
VEO 3.0 DISPLAY LAYOUT
VEO 3.0
2-Gauge Combo
VEO 3.0 Wrist
VEO 3.O
3-Gauge NavCon
