Oldal 1/12
4K LED MONITOR
430LED4K & 550LED4K
INSTRUCTION MANUAL
Please read this manual thoroughly before use, and keep it handy for future reference.
4K LED MONITOR 430LED4K & 550LED4K
2
CONTENTS
GENERAL INFORMATION ..............................................................................................................................3 1.
PRODUCT DESCRIPTION AND TYPE OF USE ..........................................................................................3 1.1.
GENERAL FEATURES 3 1.1.1. ......................................................................................................................
OPENING THE BOX ................................................................................................................................3 1.2.
CONTENTS OF THE BOX ................................................................................................................3 1.2.1.
WARNINGS 3 1.3. ............................................................................................................................................
POWER ..........................................................................................................................................3 1.3.1.
SAFETY PRECAUTIONS ..................................................................................................................3 1.3.2.
INSTALLATION PRECAUTIONS .......................................................................................................4 1.3.3.
CLEANING THE DEVICE 4 1.3.4. .................................................................................................................
PRIVACY AND COPYRIGHT ............................................................................................................4 1.3.5.
ONTROLS & SETTINGS 5 ..................................................................................................................................2.
Controls: ...............................................................................................................................................5 2.1.
Control key board: ........................................................................................................................5 2.1.1.
4K LED OSD MENU CONTROLS .............................................................................................................5 2.2.
REGION ADJUST ............................................................................................................................5 2.2.1.
1P ..................................................................................................................................................6 2.2.2.
2P LR .............................................................................................................................................6 2.2.3.
2P TB .............................................................................................................................................7 2.2.4.
2P PIP ............................................................................................................................................8 2.2.5.
4P ..................................................................................................................................................8 2.2.6.
SET 9 2.2.7. ................................................................................................................................................
Product specicaons ............................................................................................................................... 113.
4K LED MONITOR 430LED4K & 550LED4K
3
GENERAL INFORMATION 1.
Dear Customer,
Thank you for having purchased this product. This document describes how to install and use the LCD color
monitor. Read this manual which contains informaon for correct, safe use carefully. Keep this manual at
hand so that you can refer to it when needed.
PRODUCT DESCRIPTION AND TYPE OF USE 1.1.
The LED color monitor presents a very rugged structure. It is designed for connuous operaon and can be
used in closed circuit TV systems without risks of excessive fague. The Flat Panel Display has an acve
matrix, thin-lm transistor (TFT), liquid crystal display (LCD).
GENERAL FEATURES
1.1.1.
- Display area
- Wall mounng with not included bracket
- Socket audio input/output
- HDMI 1.4 & HDMI 2.0 & DP1.2 video input
Mullingual OSD menu for easy seng and opmizaon of the display
OPENING THE BOX 1.2.
Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if parts
are either missing or damaged. Do not aempt to use the device in this case. Send the product back in its
original packing if it is damaged.
CONTENTS OF THE BOX 1.2.1.
- LED monitor
- Remote Control
- Power Adaptor (Only in 28inch, 32”)
- Power cable
- HDMI cable
- User’s manual
Important Note: Accessories may be changed without prior noce.
WARNINGS 1.3.
POWER 1.3.1.
- Only use the power unit provided to power the device. Check mains rang before plugging the
power unit in.
- Do not pull the cable to unplug the device.
SAFETY PRECAUTIONS 1.3.2.
- Keep the device away from rain and humidity to prevent risk of re and electrocuon. Do not
introduce material (solid or liquid) inside. If this should accidentally occur, disconnect the
device from the mains and have it inspected by qualied personnel.
- Never open the device. In all cases, contact the qualied personnel or authorized service center
for repairs.
- Keep the device away from children, to prevent accidental damage.
- Do not touch the device with wet hands to prevent electrical shock or mechanical damage.
- Do not use the device if it should fall or the external casing is damaged. Risk of electrocuon if
the device is used in such condions. Contact the retailer or authorized installer.
- It is advisable to disconnect the power wire if the monitor is not used for a certain me.
