OWNER’S MANUAL
Microwave Oven
This owner’s guide book is for the following 550 Watts microwave oven models:
PMO-555
1. READ these instructions carefully before installing and operating the oven. Keep them for further refer-
ence.
2. Record in the space below the MODEL NO. and the SERIAL NO. found on the nameplate on your oven
and retain this information for future reference.
MODEL NO. SERIAL NO.
Then complete the registration card which is attached to the warranty card, and return it.
YOU ARE REQUIRED TO PRESENT YOUR BILL OF SALE WHEN REQUESTING WARRANTY REPAIRS.
For customer service or product assistance,
please telephone our call centre
1300 657 888
IF NONE OF THE ABOVE RECTIFY THE SITUATION, THEN CONTACT THE NEAREST
AUTHORIZED SERVICE AGENT WITH QUALIFIED THCHNICIAN. DO NOT TRY TO
ADJUST OR REPAIR THE OVEN YOURSELF.
SPECIFICATIONS
Power Consumption:
output:
Operating Frequency:
Outside Dimensions:
Oven Cavity Dimensions:
Oven Capacity:
Cooking Uniformity:
Uncrated Weight:
240V, 50Hz 900W
550w
2,450MHz
245mm(H) x 443mm(W) x 305mm(D)
158mm(H) x 272mm(W) x 272mm(D)
12 litres
Turntable system (0.25.5mm)
Approx. 12.5kg
BEFORE YOU CALL FOR SERVICE
1. If the oven will not perform at all, the dis-
play does not appear or the display
disappeared:
a) Check to ensure that the oven is plugged in
securely. If it is not, remove the plug from
the outlet, wait 10 seconds and plug it in a-
gain securely.
b) Check the premises for a blown circuit fuse
or a tripped main circuit breaker. If these
seem to be operating preperly, test the outlet
with another appliance.
2. If the microwave power will not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely
closed to engage the safety interlocks. Other-
wise, the microwave energy will not flow into
the oven.
RADIO INTERFERENCE
Microwave ovens may cause interference to your radio, TV, or similar equipment. When interfer
ence occurs, it may be eliminated or reduced by the following procedures.
a. Clean the door, and sealing surface of the oven.
b. Place the radio, TV, etc. as far away from your microwave oven as possible.
c. Use a properly installed antenna for your radio,TV, etc to get a strong signal reception.
1
INSTALLATION
1. Make sure all the packing materials are re-
moved from the inside of the door.
2. Inspect the oven after unpacking for any vi-
sual damage such as:
Misaligned Door
Damaged Door
Damaged Door Seal
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT
use the oven
enough to support this weight.
4. The oven must be placed away from high
temperature and steam.
5. DO NOT place anything on top of the oven.
6. Keep the oven at least 8 cm away from both
sidewalls and 10 cm away from rear wall to
ensure the correct ventilation.
7. DO NOT remove the turn - table drive shaft.
8. As with any appliance, close supervision is
necessary when used by children.
3. This Microwave Oven weighs 12.5 kg and
must be placed on a horizontal surface strong
WARNING - THIS APPLIANCE MUST BE EARTHED.
1. The power cord is 1.4 m long, the plug socket should be within easy reach of this cord.
2. This oven requires 0.9 KVA for its input.
consultation with service engineer is suggested CAUTION: This oven is protected internally
when installing the oven.
by a 250V, 6 Amp Fuse.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green - and - yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains leads of the appliance may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green - and - yellow must be connected to the terminal in the
plug which is marked with the letter E or by the earth symbol-coloured green or green -
and - yellow
The wire which is coloured blue must be connected to the terminal which is marked with the
letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with
the letter L or coloured red.
2
