User Manual
PCE-CSM 10 Colorimeter
EN
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@pce-instruments.com
www.pce-instruments.com/english
www.pce-instruments.com
MANUAL
© PCE Instruments
CONTENTS
INDUCTION ............................................................................................................................................................... 1
CAUTIONS ................................................................................................................................................................. 1
1. INTERFACE DESCRIPTION ................................................................................................................................ 2
2 .BATTERY DESCRIPTION .................................................................................................................................... 3
3. BATTERY INSTALLATION .................................................................................................................................. 3
4. OPERATING INSTRUCTION ............................................................................................................................... 4
4.1TURN ON ...................................................................................................................................................................... 4
4.1.1 Preparations ........................................................................................................................................................ 4
4.1.2 Turn On ................................................................................................................................................................ 4
4.2 WHITE CALIBRATION AND BLACK CALIBRATION ......................................................................................................... 5
4.3 MEASUREMENT ........................................................................................................................................................... 6
4.3.1 Measurement Locating ........................................................................................................................................ 6
4.3.2 Standard Measurement ................................................................................................................................... 6
4.3.4 Measure and View Spectral Reflectance Graph ................................................................................................... 8
4.4 CONNECTING TO PC .................................................................................................................................................... 9
4.5 PRINT........................................................................................................................................................................... 9
5. SYSTEM FUNCTION DESCRIPTION ................................................................................................................. 9
5.1 DATA MANAGEMENT ................................................................................................................................................. 10
5.1.2 Check Spectral Reflectance Curve ...................................................................................................................... 12
5.1.3 Editing Record Name ......................................................................................................................................... 13
5.1.4 Deleting a Single Record .................................................................................................................................... 14
5.1.5 Turning Standard Record into Measurement Standard ..................................................................................... 14
5.1.6 Turning Sample Record into Measurement Standard ........................................................................................ 14
5.1.7 Deleting All Records ........................................................................................................................................... 14
5.1.8 Standard Input ................................................................................................................................................... 15
5.2 TOLERANCE SETTING ................................................................................................................................................ 16
5.3 LIGHT SOURCE SETTING ............................................................................................................................................ 17
5.4 AVERAGE MEASUREMENT ......................................................................................................................................... 18
5.5 COLOR OPTIONS ........................................................................................................................................................ 19
5.5.1 Color Space ........................................................................................................................................................ 20
5.5.2 Color Index ......................................................................................................................................................... 25
5.5.3 Observer Angle .................................................................................................................................................. 30
5.7 FUNCTION SETTING ................................................................................................................................................... 32
5.7.1 Auto Save ........................................................................................................................................................... 32
5.7.2 Time Set ............................................................................................................................................................. 32
5.7.3 Language Selection ............................................................................................................................................ 35
5.7.4 Backlight Time ................................................................................................................................................... 35
5.7.5 Screen Brightness .............................................................................................................................................. 35
5.7.6 Buzzer Switch ..................................................................................................................................................... 35
5.7.7 Restore Factory Settings .................................................................................................................................... 36
6.TECHNICAL PARAMETERS ............................................................................................................................... 37
6.1 PRODUCTS FEATURES ................................................................................................................................................ 37
6.2 TECHNICAL SPECIFICATIONS ...................................................................................................................................... 38
MANUAL
© PCE Instruments
Induction
PCE-CSM 10 spectrophotometer is independently developed by PCE which is in
accordance with CIE (International Commission on Illumination) and CNS (China
National Standards). The instrument features with touch screen and large screen display. It
is configured with high-end color quality management software. Meanwhile it has characters
of stable performance, precise measurement and easy to use. The instrument is powered by
Li-ion battery or DC power adapter.
Advantages
1. Touch screen, easy to operate.
2. Large screen (3.5 inch), high resolution (320*480), full-view display with clear image.
3. Aesthetic design perfectly combined with ergonomics structure.
4. D/8 geometry optical structure, accord to CIE, ISO, ASTM, DIN Standards.
5. Two standard observer angles, multiple light sources modes, a variety of color
systems.
6. High hardware configuration with a number of innovative technologies.
7. Oversized integrating sphere, more effective homogenization ray of lights and precise
measurement.
8. Visible spectrum 400~700nm reflectance curve.
9. Input standard data manually, easy to operate.
Cautions
● The spectrophotometer is a precise measuring instrument. Please avoid dramatic changes
of external environment when measuring. These changes, including the flicker of
surrounding light and the rapid change of temperature, will affect measurement accuracy.
● Keep the instrument balanceable; make sure the measuring aperture close to the test
sample, and no shaking or shifting when measuring. Please prevent the colorimeter from
fierce collision or crash.
● The instrument is not waterproof. Do not use it in high humidity environment or in water.
● Keep the instrument clean. Avoid dust, powder or solid particles entering the measuring
aperture and the instrument.
● Replace the white calibration cavity and put the spectrophotometer into instrument case
when not in use.
● Please take out the battery to prevent the instrument from damage if you don’t use it for a
long time.
● Please keep the instrument in a cool dry place.
● Any unauthorized changes to the instrument are not permitted, or it will affect the
measuring accuracy, even cause irreversible damage.
