Oldal 1/12
• Class D Topology
• Selectable Balanced / Unbalanced Inputs
• Surface-Mount Component Technology
• Multi-Input Selector
• Low Pass and Subsonic Crossovers (GX1200.1)
• Proprietary PG Quick Connects
• Flush Mountable Bass Knob
• Full Radiation Heat Sink
• Single-sided Control Panel
• Onboard Short/Therm/Imped Protection
• 0-180° Variable Phase Shift (GX1200.1)
GX
New for 2021 is Phoenix Gold’s GX line of ampliers.
Designed to cover a multitude of installation needs,
GX is packed with the features and power you can
expect from the Phoenix Gold brand. Included in the
line are our proprietary PG quick connects for high
current capability and reliability while delivering uber
clean and quick installations. The chassis has been
optimized by utilizing BFD (Balanced Flow Dissipation)
to keep the amplier running cool when the music is hot.
© 2020 Phoenix Gold • www.phoenixgold.com
Designed and Engineered in the USA
Expertly Manufactured in China
A Power Brand of AAMP Global.
15500 Lightwave Drive, Suite 202
Clearwater, Florida 33760
P: 866-788-4237
info@phoenixgold.com
www.phoenixgold.com
Phoenix Gold Product Warranty
LIMITED WARRANTY ON AMPLIFIERS
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) years
from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an
authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty
for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the
defective product with new or remanufactured product at no charge. Damage caused by the following is not covered
under warranty: accident, misuse, abuse, product modication or neglect, failure to follow installation instructions,
unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover incidental or consequential
damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or
normal wear and tear is not covered under warranty. Additional warranty coverages are available, see your warranty
card for specic options based on your geographic region and product.
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold
reseller and not by Phoenix Gold. Consumers needing service or warranty information for these products must contact
that country’s reseller for information.
© 2020 Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
GX1200.6 SPECIFICATIONS
IMPORTANT: A power birth certicate is included for each amplier. GX ampliers are
conservatively rated and will exceed their RMS power rating shown here.
All RMS power ratings and measurements are at 14.4 volts with no more than 1% THD.
Remote Bass Controller:
Flush mount level controller. Fine tune your bass output with a simple
turn of the precision controller. 16ft of cable included.
GX 1200.6 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 6
4Ω: CH 1-6 125W x 6
2Ω: CH 1-6 200W x 6
4Ω Bridged: 400W x 3
Total RMS Power (Sum of rated power):
1200W
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FULL/HP/LP
40Hz - 500Hz @ 12dB/Oct
Input Selection: 0.4-10V
Signal to Noise (@ CEA Standard): >100dB
Frequency Response: Full Range 10-40k
Topology Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 8V to 16V
Switchable Auto-Turn On: No
Power Supply Type: Unregulated
Power Terminal: 4 Gauge Quick Connect
Speaker Terminal: 8 Gauge Quick Connect
Recommended Fusing: 80A
Dimensions (L x W x H): 13.54” x 6.5” x 2.03”
344mm x 165mm x 51.5mm
13.54in / 344mm
2.03in / 51.5mm
6.5in / 165mm
