1. Package Contents
Before start installing the Converter, verify the package
contains the following parts:
● TheMediaConverterChassisx1
● User'sManualx1
● MountingAccessory(for10/19”ChassisShelf)x1
● RubberFeetx4
● ACPowerCordx1
Ifanyofthesearemissingordamaged,pleasecontactyour
dealer immediately, if possible, retain the carton including
the original packing material, and use them against to
repacktheproductincasethereisaneedtoreturnittous
for repair.
3. Media Converter Chassis
Front Panel
Figure 3-1 & 3-2 & 3-3 shows a front panel of MC-700 /
MC-1500/MC-1500R/MC-1500R48.
Figure 3-1 MC-700 Front Panel
Figure 3-2 MC-1500 Front Panel
Figure 3-3 MC-1500R / 1500R48 Front Panel
6. Installing the Media Converter
Chassis
6.1 Installing Media Converter Chassis to
10/19-inch Wiring Closet Rack
» Installfourscrewsthroughmountingearsintoeachside.
» Locate Converter Chassis at 10/19-inch mounting rails
andscrewupthefrontbrackets.
» Set Main power switch at “OFF” position before
connectingthepowercord.
Figure 6-1 InstallingMediaChassisinWiringClosetRails
5. Media Converter Chassis
Rear Panel
Figure 5-1 & 5-2 & 5-3 shows a rear panel of MC-700 /
MC-1500/MC-1500R/MC-1500R48.
The rear panel of the MC-700 is with one fan, one ON/
OFF Switch and a power inlet that accept 100~240V AC,
50/60Hzpowerinput.
Figure 5-1 MC-700 Rear Panel
The rear panel of the MC-1500 is with two fans, one ON/
OFF Switch and a power inlet that accept 100~240V AC,
50/60Hzpowerinput.
Figure 5-2 MC-1500 Rear Panel
2. Product Features
● Highquality10"
/
19”Rack-MountableChassisinstallation
● Supports up to seven (7) / fteen (15) hot-swappable
mediaconverters
● One fan brings the air-ow for system cooling, and LED
indicatorsforsystemandfanstatus(MC-700)
● Two fan brings the air-ow for system cooling, and LED
indicatorsfor systemandfanstatus(MC-1500 /1500R/
1500R48)
● Thepowerslotatrearpanelforredundantpowersupport
with options of 100~240V AC or -48V DC supplies
(MC-1500R/1500R48)
● Bay power isolation, ensure each bay is electrically
isolatedfromeachother
● Support multiple converters with 10/100/1000Mbps,
copper,Fiber,single/multi-modeST/SC/SFPconnectors
● Reducetheeffort ofconvertermaintenance andmanage-
ment,diagnosethestatusatonetime
● Cost-effective,easyinstall
4. LED Indicators
MC-700
Printing LED
Status Description
PWR
ON Thechassisispowered.
OFF
Thechassisisnotpoweredorpower
failure,iftheACoutletiswith
100~240VACvoltage.Pleaseconsult
yourlocaldealerifpowerfailure.
FAN
ON Thefanisfunctionalok.
OFF
Thefanisnotpoweredoritis
malfunction.IfthefanLEDremains
offwhilepowerison.Pleaseconsult
yourlocaldealertoreplacetheFAN.
MC-1500 Series
Printing LED
Status Description
PWR
ON Thechassisispowered.
OFF Thechassisisnotpoweredorpower
failure.
FANA/
FANB
ON ThefanisfunctionalO.K.
OFF
Thefanisnotpoweredoritis
malfunction.IfthefanLEDremains
offwhilepowerison.Pleaseconsult
yourlocaldealertoreplacetheFAN.
TherearpaneloftheMC-1500R/1500R48.
Figure 5-3 MC-1500R / 1500R48 Rear Panel
Note
1.TheMC-1500Rshippedwithone100~240V
ACpowersupplymodule(MC-15RPS130).
2.TheMC-1500R48shippedwithoneDC-48V
powersupplymodule(MC-15RPS48).
Power
Notice
1.Thedeviceisapower-requireddevice,it
means,itwillnotworktillitispowered.
Ifyournetworksshouldactiveallthe
time,pleaseconsideruseaproperUPS
(UninterruptedPowerSupply)foryour
device.Itwillpreventyoufromnetwork
datalossornetworkdowntime.
2.Insomearea,installingasurge
suppressiondevicemayalsohelpto
protectyourchassisfrombeingdamaged
byunregulatedsurgeorcurrenttothe
converterorthepoweradapter.
Rack Mount Instructions
A) Elevated Operating Ambient - If installed in a closed or
multi-unitrackassembly,theoperatingambienttemper-
ature of the rack environment may be greater than
room ambient.Therefore,considerationshouldbegiven
to installing the equipment in an environment compat-
ible with the maximum ambient temperature (Tma)
speciedbythemanufacturer.
B) Reduced Air Flow - Installation of the equipment in a
rackshouldbesuchthattheamountofairowrequired
forsafeoperationoftheequipmentisnotcompromised.
C) Mechanical Loading - Mounting of the equipment in the
rack should be such that a hazardous condition is not
achievedduetounevenmechanicalloading.
D) Circuit Overloading - Consideration should be given to
the connection of the equipment to the supply circuit
andtheeffectthatoverloadingofthecircuitsmighthave
onovercurrentprotectionandsupplywiring.Appropriate
considerationofequipmentnameplateratings shouldbe
usedwhenaddressingthisconcern.
E) Reliable Earthing - Reliable earthing of rack-mounted
equipment should be maintained. Particular attention
should be given to supply connections otherthan direct
connections to the branch circuit (e.g. use of power
strips)."
- 9 -
- 10 -
- 11 -
- 12 - - 13 - - 14 -
6.2 Installing Converters to the Media Converter
Chassis
» TurnofftheConverterChassispower.
» Verify the Media Converter is right for this Chassis and
locate +5VDC power jack on converter back, carefully
slide in and plug to match 10”/19” Chassis slot +5V
DC receptacle. Push up the picket fence to lock the
converters.
Note
The slide-in Media Converters and Converter
Chassis should be supplied only from PLANET,
both Media Converters and Chassis are built
to matcheachother atdimensions,DCpower
jack,andDCreceptacleandpowersafety.
» Ensurethatthereisnoactivityinthenetwork.
» Connectthemediacablefornetworkconnection.
» Turnonthe chassispower, the PowerLED,andboth FAN
LEDindicatorswilllightup.
7. Product Specications
MC-700 Converter Chassis Specications
Dimension 217mmx88.5mmx140mm
(WxHxD),2Uheight
Converter Slots 7slots
Power Input 100~240VAC,50/60Hz
Power
Consumption 40Wattsmaximum/136BTU
Power Output
Per Slot +5VDC
DC Plug Per Slot 2.5mmDCreceptacle
LED Indication 2;Power,FAN
FAN 1
Temperature /
Humidity
Operating Environment
0~50DegreeC;Humidity:5~90%
non-condensing
Storage Environment
-40~70DegreeC;Humidity:5~90%
non-condensing
Emission FCCPart15ClassA,CE
6.3 Converter Check Point
Fiber
Port
Attachtheber
cable.TheTx,
Rxbercable
mustbepaired
atbothends.
2.5mm
DCReceptacle2.5mm
+5Vforeachslot
DCreceptacleis2.5mmwide
thatconformstoandmatches
theMediaConverter2.5mmDC
jack'scentralpole.Donotinstall
anyimproperunit,modelofthe
MediaConverter.
TP
Port
Attach UTP
Cat. 3 or 5 ca-
ble to TP port.
Note
For safety reason, it is recommended storing
the AC adapter of the converter in a known
securedplace.Formoreaboutconverter,refer
totheuser guideoftheconverter.
MC-1500 Converter Chassis Specications
Dimension 440mmx103mmx180mm
(WxHxD),2.4Uheight
Converter Slots 15slots
Power Input 100~240VAC,50/60Hz
Power
Consumption 70Wattsmaximum/238BTU
Power Output
Per Slot +5VDC
DC Plug Per Slot 2.5mmDCreceptacle
LED Indication 3;Power1,FANA,FANB
FAN 2
Temperature /
Humidity
Operating Environment
0~50DegreeC;Humidity:5~90%
non-condensing
Storage Environment
-40~70DegreeC;Humidity:5~90%
non-condensing
Emission FCCPart15ClassA,CE
MC-1500R / MC-1500R48 Converter Chassis
Specications
Model MC-1500R MC-1500R48
Dimension 440mmx103mmx180mm
(WxHxD),2.4Uheight
Converter Slots 15slots
Power Input 100~240VAC,
3.3A,50-60Hz
DC-48V,2A,
Range:-40V~-60V
Power
Consumption
10.7Watts/36BTU
(1xpowersupply,
notinclude
converters)
88.3Watts/301BTU
(Fullloading)
5.3Watts/18BTU
(1xpowersupply,
notinclude
converters)
80Watts/272BTU
(Fullloading)
Power Output
Per Slot Eachslot5V
1A
DC Plug Per
Slot 2.5mmDCreceptacle
LED Indication 4;Power1,Power2,FANA,FANB
FAN 2
Temperature /
Humidity
Operating Environment
0~50DegreeC;Humidity:5~90%
non-condensing
Storage Environment
-40~70DegreeC;Humidity:5~90%
non-condensing
Emission FCCPart15ClassA,CE
8. Customer Support
Thank you for purchase PLANET products. You can browse
our online FAQ resource at the PLANET Web site rst to
check if it could solveyou issue. If you need moresupport
information,pleasecontactPLANETMediaConvertersupport
team.
PLANETonlineFAQ:
http://www.planet.com.tw/en/support/faq.php?type=3
MediaConvertersupportteammailaddress:
support_converter@planet.com.tw
Copyright © PLANET Technology Corp. 2012.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other
trademarks belong to their respective owners.
