Használati útmutató Prestigio MultiPhone 4020 DUO

Prestigio okostelefon MultiPhone 4020 DUO

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Prestigio MultiPhone 4020 DUO (10 oldal) a okostelefon kategóriában. Ezt az útmutatót 7 ember találta hasznosnak és 4 felhasználó értékelte átlagosan 4.4 csillagra

Oldal 1/10
PAP4020DUO EN - 1
Quick Start Guide
Prestigio MultiPhone
PAP4020DUO
EN
1. Packing List
1. Prestigio MultiPhone
2. AC Adapter
3. Earphone
4. USB Cable
5. Quick Start Guide
6. Warranty Card
7. Legal and Safety Notices
8. Battery
2. Device Overview
Earphone Jack
Earphone connection
Menu
Display menu options
Home
Back to the Home screen
Back
Back to the previous page
USB/Charge port
Micro USB cable/charge connection
Power
Turn on/off the device;
Suspend/Activate the device
Vol +\ Vol - Button
Adjust the volume level
Camera
Take photos
Speaker
Listen to phone calls or music
9
8
7
6
5
4
3
2
1
1
2
4
8
3
5
6
7
9
EN-2 PAP4020DUO
Quick Start Guide
Prestigio MultiPhone
PAP4020DUO
EN
3. Uninstalling the back cover and battery
Uninstalling the back cover: hold the side of device tightly with one hand and lift up the back cover at its buckle
with the other hand.
Taking out the battery: hold the side of device tightly with one hand and pull up the battery handle with the
other hand.
Notice: Your device must be powered off before exchanging or uninstalling the battery.
4. Installing the SIM cards and Micro SD card
PAP4020DUO EN - 3
Quick Start Guide
Prestigio MultiPhone
PAP4020DUO
EN
a. Insert SIM cards
The slot at the bottom is card 1 slot and for 3G WCDMA card (compatible with 2G card), another is card 2 slot
and for GSM card.
Please make sure the gold contact area on the card is facing downwards.
b. Insert Micro SD card
Insert Micro SD card into the Micro SD card slot with the metallic pins facing downwards. Push the card until it
locks into place.
To remove the micro SD card, pull the card out of the slot.
5. Charging
Insert one end of USB cable into the USB port on the
device and plug the power adapter to the electrical socket.
Normally it takes approximately 3~4 hours to fully charge
the device. Operating the device while charging with the
AC adapter may extend the time of full charging.
Notice: If you dont use your phone for a long time, it will gradually discharge. Please charge it first before
your next use or charge the phone every 3 months even you dont use it.
6. Power on/Sleep Mode/Power off
Press and hold the Power Button for a few seconds. It will automatically enter the Home screen after start-up
screen.
