www.PyleUSA.com

On Wall/Patio Commercial Speaker

2-Way Full Range Stereo Sound,

Waterproof Enclosure with 70V Built-in Transformer

PDWR445TB - PDWR445TW

PDWR545TB - PDWR545TW

PDWR445TB

PDWR445TW

PDWR545TB

PDWR545TW

3.5''

3.5''

5.25''

5.25''

70V

Transformer

70V

70V

70V

IP54

IP54

IP54

IP54

40W

40W

80W

80W

20W

20W

40W

40W

PDWR445TB-Black / PDWR445TW-White

Features:

• Marine Grade Waterproof Construction

• 2-Way Full Range Stereo Sound

• Custom Tooled Design for High Power and Deep Bass Response

• Removable & Rust Proof Aluminum Speaker Grills

• Gold Plated Speaker Plug Terminals

• Suitable for Wall Mounting via Adjustable Fixing Bracket.

• Heavy Duty Engineered Plastic Composite Cabinet

• Rotary Selector Switch for 70V Line Tappings or 8 ohms Operation

• Excellent for Monitor or Surround Sound Applications Option

• Great by the Pool, on the Patio or Public Address Application

• For Indoor / Outdoor Use

What's in the Box:

• (1) Speaker Enclosure

• (1) Rubber Cap x 1(To Block Ventilation Hole on Front Panel

of Enclosure to Get Waterproof Sealed)

• (1)Aluminum Mounting Bracket

• (2)Bracket Bolts

• (1)Screw Bag

Technical Specs:

• Marine Grade IP54 Rating

• 3.5'' Long Throw Woofer

• Magnet Size: 7.8 oz.

• Cone Material: Mica + Rubber Surround

• 0.5'' Polymer Dome Tweeter

• 40 Watt Rated Peak Power

• 20 Watt Rates RMS Power

• Frequency Response: 114Hz-20kHz

• 8 Ohm Impedance

• 70V Transformer Tapping: 20W/10W/5W/2.5W/8 Ohm

• Dimensions (L x W x H): 5.91'' x 4.33'' x 7.87'' -inches

PDWR545TB-Black / PDWR545TW-White

Features:

• Marine Grade Waterproof Construction

• 2-Way Full Range Stereo Sound

• Custom Tooled Design for High Power and Deep Bass Response

• Removable & Rust Proof Aluminum Speaker Grills

• Gold Plated Speaker Plug Terminals

• Suitable for Wall Mounting via Adjustable Fixing Bracket.

• Heavy Duty Engineered Plastic Composite Cabinet

• Rotary Selector Switch for 70V Line Tappings or 8 ohms Operation

• Excellent for Monitor or Surround Sound Applications Option

• Great by the Pool, on the Patio or Public Address Application

• For Indoor / Outdoor Use

What's in the Box:

• (1) Speaker Enclosure

• (1) Rubber Cap x 1(To Block Ventilation Hole on Front Panel

of Enclosure to Get Waterproof Sealed)

• (1)Aluminum Mounting Bracket

• (2)Bracket Bolts

• (1)Screw Bag

Technical Specs:

• Marine Grade IP54 Rating

• 5.25”Long Throw Woofer

• 0.5'' Polymer Dome Tweeter

• Magnet Size: 13 oz.

• Cone Material: PP Mica + Rubber Surround

• 80 Watt Rated Peak Power

• 40 Watt Rates RMS Power

• Frequency Response: 75Hz-20kHz

• 8 Ohm Impedance

• 70V Transformer Tapping: 40W/20W/10W/5W/8 Ohm

• Dimensions (L x W x H): 7.44'' x 5.75'' x 9.88'' -inches
