Oldal 1/2

TUBE ENCLOSURE

RF-1400T

Installation & Operation

Installation assistance availible at:

www.rockfordfosgate.com/rftech

R O C K F O R D F O S G A T E . C O M

600 South Rockford Drive • Tempe, Arizona 85281 United States

Direct: (480) 967-3565 • Toll Free: (800) 669-9899

Warranty

Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:

Length of Warranty

Speakers, Signal Processors, PRIME and PUNCH Ampliﬁers – 1 Year

POWER Ampliﬁers – 2 Years

Any Factory Refurbished Product – 90 days (receipt required)

What is Covered

This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in

the United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate

Dealer in another country are covered only by that country’s Distributor and not by Rockford Corporation.

Who is Covered

This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate

Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt

stating the customer name, dealer name, product purchased and date of purchase.

Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be

equivalent) at Rockford’s discretion.

What is Not Covered

1. Damage caused by accident, abuse, improper operations,water, theft, shipping.

2. Any cost or expense related to the removal or reinstallation of product.

3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center.

4. Any product which has had the serial number defaced, altered, or removed.

5. Subsequent damage to other components.

6. Any product purchased outside the U.S.

7. Any product not purchased from an Authorized Rockford Fosgate Dealer.

Limit on Implied Warranties

Any implied warranties including warranties of ﬁtness for use and merchantability are limited in duration to the period

of the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so

this limitation may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection

with the sale of the product.

How to Obtain Service

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call

1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any

product to Rockford Fosgate. You are responsible for shipment of product to Rockford.

EU Warranty

This product meets the current EU warranty requirements, see your Authorized dealer for details.

Speaker Features

•Parabolic Mica Injected Polypropylene Cone

•Butyl Rubber Surround

•Bumped Backplate with Rear Pole Piece Venting

•Stamped Steel Frame

Vented Enclosure Features

•High-Flow, Low-Noise Port

•High Current Speaker Terminal

•Integrated Metal Mesh Grille

•Covered with High Density Carpet

Before installation, disconnect the battery negative (-) terminal to prevent dam-

age to the unit, ﬁre and/or possible injury. Run the speaker cable from the amp.

When routing the speaker cable from the ampliﬁer, avoid running it close to

any sources of high current (wiring harnesses).The positive (+) speaker output

from the amp connects to the red terminal of the enclosure, and the negative (-)

connects to the black terminal.

Features

Installation

Specications

United States and/or other countries. All other trademarks are the property of their respective owners. Speciﬁcations subject to change without notice.

RF-1400T

Nominal Impedance: 4 Ohm

Power Handling (Watts): 300 RMS/1400 Max

Tuning Frequency: 36Hz

Overall Dimensions

(Diameter x Length):

13” x 26”

(33cm x 66cm)

Strip 5/8"

(16mm)

From

Amplifier
