Oldal 1/12
01/2009 B.M.
05/2009 E.R.
1230-55856-01
Printed in China
Full Range Speakers
Serial Number: Date of Purchase:
Installation & Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
T142 – 4˝
T152 – 5.25˝
T1S652 – 6.5˝ Shallow
T1652 – 6.5˝
T1462 – 4˝x 6˝
T1572 – 5˝x 7˝
T1682 – 6˝x 8˝
T1692 – 6˝x 9˝
T1693 – 6˝x 9˝ 3-Way
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate
Dealers in the United States of America or its possessions. Product purchased by consumers from an
Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and
not by Rockford Corporation.
Who is Covered
This war
ranty co
v
ers onl
y the original pur
chaser of Rockford product purchased from an Authorized
Rockf
or
d F
osgate Dealer in the United States.
In or
der to receive service,the purchaser must provide
Rockf
or
d with a cop
y of the r
eceipt stating the customer name
, dealer name,product purchased and date of
pur
chase
.
Pr
oducts f
ound to be defective during the warranty period will be repaired or replaced
(with a pr
oduct deemed to be equivalent) at Rockf
or
d's discr
etion.
What is Not Covered
1. Damage caused by accident, abuse,improper operations, water, theft, shipping
2.Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4.Any product which has had the serial number defaced, altered, or removed
5. Subsequent damage to other components
6.Any product purchased outside the U.S.
7.Any product not purchased from an Authorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above.Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply.No person is authorized to assume for Rockford Fosgate any other
liability in connection with the sale of the product.
Ho
w to Obtain Ser
vice
Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further
assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment
of product to Rockford.
EU
W
arr
anty
This product meets the current EU warranty requirements, see your Authorized dealer for details.
Designed and Engineered by Rockford Fosgate,Tempe,AZ. USA.
2009 Rockford Corporation.All rights reserved.
Rockf
or
d F
osgate and the Rockf
or
d F
osgate logo are either
registered trademarks or trademarks of Rockford Corporation.
LIMITED WARRANTY ST
A
TEMENT
Rockford Fosgate
Rockford Corporation
600 South Rockford Drive
Tempe,Arizona 85281 U.S.A.
In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899
www
.r
ockfordfosgate.com
2
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to
install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the
installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers
in place.
4. Use high quality connectors for a reliable installation and to minimize signal or
power loss.
5.
Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,
brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle. If installation in a boat, take care not to cut or drill through the main hull.
6. Never run wires underneath the vehicle. Running the wires inside the vehicle or
hull area provides the best protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic
grommets to protect any wires routed through metal, especially the firewall.
1.
Determine wher
e the speak
ers will be mounted. Ensure an area large enough for
the speaker to mount evenly. Be sure that the mounting location is deep enough
f
or the speak
er to fit;
if mounting in a door
,
operate all functions (windo
ws,
locks,
etc.) through their entire operating range to ensure there is no obstruction.
2. Refer to the specification chart to determine the proper diameter hole to cut
f
or y
our speak
er model.
Cutting and mounting templates can be f
ound at
www.rockfordfosgate.com.
3. Mark the locations for the mounting screws. Drill the holes with a 1/8" bit.
4.
F
eed the speak
er wir
es thr
ough the cutout and connect to the speaker terminals.
Be sure to observe proper polarity when connecting the wires.The speaker's
positive terminal is indicated with a "+".
5a.
On models with slotted holes,
fit the speaker into the cutout and install the
screws in the slots at the top and bottom.This will allow you to rotate the speak-
er to match the remaining mounting holes.When aligned, tighten the screws.
5b. On models with a trim ring, fit the trim ring over the speaker and mount into
place using four (4) screws.
6.
Tighten the scr
e
ws until the speak
er is sn
ug in place to pr
event rattling. Do not
over tighten the screws.
NOTE: For T142, T1462, T152, T1S652, T1652 and T1572 only, if needed use
the adapter plate pr
ovided to mount the speaker. See Adapter Plate
T
emplates at the end of this manual.
SAFETY
CARTON CONTENTS
CAUTION: Before installation, disconnect the battery
negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
• (1) Set T1 Series Full Range Speakers
• (1) Set of grilles (T152,T1S652,T1652,T1692 and T1693 Only)
• (1) Pair of 4”x6”/6”x8” adapter plates (T142,T1462, and T1572 Only)
• (1) Pair of 5”x7”/6”x9”adapter plates (T152,T1S652, and T1652 Only)
• Mounting Hardware
INSTALLATION CONSIDERATIONS
MOUNTING
T142,
T152 and T1S652 Only
sna
p!
Removing tabs for
some in
stallations
Break off
mou
nting tab.
Use pl
iers to break off
plastic tab.
Cutout
Hole
Position to
Ali
gn Holes
Example of standard
doo
r installation
Rear
Deck
Cutout
Hole
Example of
rear deck installation
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
ma
y produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
3
Specifications subject to change without notice.
Specifications subject to change without notice.See figures on following pages.
See figures on following pages.
T1 Full-Range
T142 T152 T1S652 T1652 T1462
Nominal Diameter - inch (mm) 4.0 (102) 5.25 (133) 6.5 (165) 6.5 (165) 4 x 6 (102 x 152)
Description 2-Way 2-Way 2-Way 2-Way 2-Way
Nominal Impedance (ohms)
4Ω 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz) 90Hz - 22kHz 65Hz - 22kHz 65Hz - 22kHz 55Hz - 22kHz 75Hz - 22kHz
Voice Coil Diameter - inch (mm) 1.1 (28) 1.1 (28) 1.1 (28) 1.2 (31) 1.1 (28)
Fs - Free Air Resonance (Hz) 90 Hz 65 Hz 65 Hz 55 Hz 75 Hz
Qts 0.85 0.60 0.70 0.50 0.84
Vas - cu. ft. (Liter) 0.12 (3.5) 0.34 (9.7) 0.39 (11.0) 0.57 (16.0) 0.22 (6.4)
Xmax - inch (mm) 0.10 (2.5) 0.16 (4.0) 0.18 (4.5) 0.24 (6.0) 0.12 (3.0)
SPL (dB @ 1w/1m) 86 dB 86.5 dB 88 dB 89 dB 85.5 dB
Power Handling-Watts (RMS / Peak) 40 / 80 60 / 120 70 / 140 75 / 150 45 / 90
Recommended Amp Power-Watts (RMS) 12W ~ 40W 18W ~ 60W 21W ~ 70W 22.5W ~ 75W 13.5W ~ 45W
Mounting Diameter-inch (mm) 4.06 (103) 4.80 (122) 5.04 (128) 5.59 (142) 3.78 x 5.79 (96 x 147)
Mounting Depth-inch (mm) 1.79 (46) 2.03 (52) 1.93 (49) 2.51 (64) 2.00 (51)
Includes Speaker Grilles NO YES YES YES NO
Grille Ring Diameter-inch (mm) – 6.22 (158) 6.89 (175) 6.97 (177) –
Grille Ring Height-inch (mm) – 1.18 (30) 1.18 (30) 1.22 (31) –
Includes Multi-OEM Adapter Plate
4”x6”/6”x8” 5”x7”/6’x9” 5”x7”/6’x9” 5”x7”/6’x9” 6”x8”
T1 Full-Range
T1572 T1682 T1692 T1693
Nominal Diameter - inch (mm) 5 x 7 (127 x 178) 6 x 8 (152 x 203) 6 x 9 (152 x 229) 6 x 9 (152 x 229)
Description 2-Way 2-Way 2-Way 3-Way
Nominal Impedance (ohms) 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz)
60Hz - 22kHz
55Hz - 22kHz
50Hz - 22kHz 50Hz - 22kHz
Voice Coil Diameter - inch 1.1 (28) 1.2 (31) 1.2 (31) 1.2 (31)
Fs - Free Air Resonance (Hz) 60 55 50 50
Qts 0.90 0.60 0.60 0.60
Vas - cu. ft. (Liter) 0.44 (12.5) 0.64 (18) 0.88 (25) 0.88 (25)
Xmax - inch (mm) 0.18 (4.5) 0.20 (5.0) 0.24 (6.0) 0.24 (6.0)
SPL
(dB @ 1w/1m) 87 dB 88 dB 90 dB 90 dbB
Power Handling-Watts (RMS / Peak) 70 / 140 80 / 160 100 / 200 100 / 200
Recommended Amp Power-Watts (RMS) 21W ~ 70W 24W ~ 80W 30W ~ 100W 30W ~ 100W
Mounting Diameter-inch (mm)
4.80 x 7.13 (122 x 181) 5.08 x 7.32 (129 x 186) 5.78 x 8.58 (147 x 218) 5.78 x 8.58 (147 x 218)
Mounting Depth-inch (mm)
2.30 (59)
2.60 (66)
3.43 (87)
3.43 (87)
Includes Speaker Grilles NO NO YES YES
Grille Ring Diameter-inch (mm)
–
– 7.56 x 10.24 (192 x 260) 7.56 x 10.24 (192 x 260)
Grille Ring Height-inch (mm) – – 1.34 (34) 1.30 (33)
Includes Multi-OEM
Ada
pter Plate
6”x8” NO NO NO
SPECIFICATIONS
SPECIFICATIONS
