Oldal 1/13
1
INSTRUCTION MANUAL
ESPRIT 100 ED Super APO
Copyright © Sky-Watcher
SL131203
1
Table of contents
Table of Contents
Introduction ........................................................................................................................................ 2
Getting started ................................................................................................................................... 3
Parts description .................................................................................................................................. 3
Unpacking the telescope ...................................................................................................................... 3
Preparing the telescope for an observation .......................................................................................... 4
Cooling the telescope .......................................................................................................................... 4
Aligning the finder scope .................................................................................................................... 5
Using the telescope for visual observation ............................................................................ 6
Inserting the eyepiece .......................................................................................................................... 6
Focusing .............................................................................................................................................. 6
Using the telescope for prime focus imaging ....................................................................... 7
Installing the field flattener and a DSLR (Digital Single-Lens Reflex) camera .................................. 7
Installing the field flattener and a CCD (Charge-Coupled Device) camera ........................................ 8
Installing the field flattener and a CCD camera - continued ............................................................... 9
Focusing .............................................................................................................................................. 9
Framing the picture ............................................................................................................................. 9
Useful tips for all observations ................................................................................................ 10
Removing the finder scope ................................................................................................................ 10
Using the indexed scale ..................................................................................................................... 10
Rotating the focuser........................................................................................................................... 10
Specifications .................................................................................................................................. 11
Telescope specifications .................................................................................................................... 11
Threads specifications ....................................................................................................................... 11
2
Introduction
The spirit of perfection, by Sky-Watcher
Designed with the discerning astronomer in mind, Sky-Watcher top-of-the-line Esprit refractors
deliver the kind of imaging performance one would expect from telescopes costing much more. With
their three-element air spaced objective lens design, false color is completely eliminated, yielding
exceptional contrast and sharpness.
The 3" CNC machined 1:11 rotatable dual speed linear power focuser provides a smooth, rock-solid
focusing with zero image shifts. The Esprit ED 100mm refractor comes with a 9 x 50 right angle
finder scope, 2-inch Star diagonal, D-style dovetail, eyepiece, retractable dew cap and padded case.
Everything you need to get out under the stars.
The 2-element thread-on 48mm field flattener guarantees excellent field flatness across the entire 40
mm imaging plane. Its oversized lenses ensure a larger and clearer aperture and also extremely
minimized halation.
Quick overview:
• 100 mm apochromatic, 3-element refractor
• 550 mm (f/5.5)
• Metallic high-transmission lens coatings
• 3" CNC machined 1:11 dual-speed focuser
• Zero color fringing even on bright objects
• 40 mm image circle
• Knife-edge Baffled Optical System
• 2" Diagonal with dielectric coatings
• 9x50 erect-image 90° finder scope
• Tube rings with dovetail D (Losmandy style) bar
• Aluminum foam lined case
• Thread-on field flattener
• Full frame corrected focal plane
NEVER USE YOUR TELESCOPE TO LOOK DIRECTLY AT
THE SUN. PERMANENT EYE DAMAGE WILL RESULT.
NEVER USE AN EYEPIECE-TYPE SOLAR FILTER.
NEVER USE YOUR TELESCOPE TO PROJECT SUNLIGHT
ONTO ANOTHER SURFACE; THE INTERNAL HEAT BUILD-
UP WILL DAMAGE THE TELESCOPE OPTICAL ELEMENTS.
USE A PROPER SOLAR FILTER FIRMLY MOUNTED ON THE
FRONT OF THE TELESCOPE FOR VIEWING THE SUN.
WHEN OBSERVING THE SUN, PLACE A DUST CAP OVER
YOUR FINDERSCOPE OR REMOVE IT TO PROTECT YOU
FROM ACCIDENTAL EXPOSURE.
NEVER LET A TELESCOPE POINTING THE SUN
UNATTENDED.
