DVI-D Extender

EXTENDS DVI-D

UP TO 225 FEET

OVER A CAT6 CABLE

Quick Start Guide

VIDEO

FormatDVI-D Single Link

Maximum Pixel Clock165 MHz

Input Interface (TX)(1) DVI-D 29-pin female

Output Interface (RX)(1) DVI-D 29-pin female

ResolutionUp to 1920 x 1200 @60Hz

DDC5 volts p-p(TTL)

Input EqualizationAutomatic

Input/Output Cable

Length

Up to 20 ft.

Extension over Cat6Up to 225 ft.

OTHER

Power

External 100-240 VAC/5VDC2A

@10W

Dimensions2.75” W x 0.8” H x 3.4” D

Weight0.2 lb

Operating Temp.0-55 °C (32-131°F)

Storage Temp.-20-85 °C (-4-185 °F)

HumidityUp to 95%

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

DVX-200

WHAT’S IN THE BOX

PART NO.DESCRIPTIONQ-TY

DVX-RX2001

DVX-200 Receiver. DVI

Receiver over CAT6 STP

DVX-TX200 1

DVX-200 Transmitter. DVI

Transmitter over CAT6 STP

DVI-D Cable16ft MM DVI-D

Power Supply2PS5VDC2A

Quick Start Guide1
