©2017 SONNEMAN - A WAY OF LIGHT
1 of 2
February 13, 2017
LED Product Information and Warnings
Important
• Always disconnect the power before installing or replacing bulbs and before cleaning or other maintenance.
• Consult a qualied, licensed electrician to ensure correct branch circuit conductor.
• Please read all included assembly instructions and warnings carefully before installation. Contact
Customer Service if you have any questions or concerns. Before installation, please conrm that the xture
is compatible with your supply voltage and dimming system, if present.
• LEDs are highly sensitive electronic devices, and must be treated with care. Do not open any factory
sealed compartments, and avoid touching the LEDs with your hands or any object.
• Although all our xtures are equipped with protective devices, LED xtures are vulnerable to power surges
and supply variations. Do not install LED xtures on the same circuit as any motors, appliances, or HVAC
systems.
• Do not remove or bypass any LED Driver or Transformer that is provided with the xture, and do not
replace or substitute with another power supply.
• Remote LED Driver or Transformer installation must be done by a licensed electrician and in accordance
with local codes. Remote installations should be in an accessible location, as close to the xture as possible.
• Fixtures must be wired in parallel on independent leads; do not "daisy chain" multiple xtures together or
wire them in series.
• All factory-made splices and connections must remain intact. LED circuits are carefully designed and built,
and improper connections may damage the xture.
• The ends of coaxial pendant cords have been precisely stripped and split at the factory and must not be
eld cut. Excess cord or cable should be neatly coiled and reserved in the xture canopy.
• Any mounting hardware is provided for your convenience and should be used with discretion. Always use
the appropriate hardware for the mounting surface.
©2017 SONNEMAN - A WAY OF LIGHT
2 of 2
February 13, 2017
Assembly Instructions
INSTRUCTIONS D’INSTALLATION
Stix Series - 19" Square LED Pendant, 24" Square LED Pendant,
30"x6" Rectangle LED Pendant, 47"x9" Rectangle LED Pendant
Important
• Always disconnect the power before installing or replacing bulbs and before cleaning or other maintenance.
• Consult a qualied, licensed electrician to ensure correct branch circuit conductor.
Consulter un électricien qualié pour vous assurer que les conducteurs de la dérivation sont adéquats.
1. Shut off power to the outlet box (A).
2. Determine the height at which the xture is to be hung. Use the
screwdriver (B) to loosen the set screw (C). Adjust the power cord (D) to the
desired length. Tighten the set screw to set.
3. Adjust the steel cables (E) to the desired length. To shorten the cable, push the
cable up and it will be locked automatically. To lengthen the cable, lift up
on the cable and push up on the lock (F). While keeping the lock depressed,
lower the cable to the desired length. Release the lock to set (Fig. 1).
4. Reserve extra power cord (D) and steel cables (E) in the canopy (G),
and adjust the cable stops (H) so they are 12" from the canopy by
loosening the screws and sliding the stops along the cable.
Tighten the screws to secure safety cable (Fig. 2).
5. Attach mounting plate (J) to the outlet box (A). Secure with
outlet box screws (K).
6. Make appropriate electrical connections using wire nuts:
a. Connect the LED driver’s (L) live wire (black) to the live outlet box wire.
b. Connect the LED driver’s (L) neutral wire (white) to the neutral
outlet box wire.
c. Connect the xture’s ground wire (green or uncoated) to the
ground outlet box wire. If not ground is present in outlet box,
connect xture’s ground wire to the mounting plate (J) using
the green screw (included).
d. Carefully place connections in outlet box (A).
7. Install the canopy (G) to mounting plate (J) by inserting the pins (M) on
the canopy into slots (N) on the mounting plate. Slide the canopy to
the side to lock.
8. Slide the cable guide (P) to desired position by using screw driver or Allen
key to loosen the set screw and tighten it to set.
NOTE: Angle of cables and cords should not exceed 45° from the vertical.
9. Restore power to the xture.
Note
• This xture is dimmable with Electronic Low Voltage (Trailing-Edge), Incandescent (Leading-Edge), and 0-10V type
dimmers only.
Care Instructions
• Dusting: Use a clean, dry cloth.
• Cleaning: To protect the nish, avoid any harsh abrasives or chemicals.
2786, 2787, 2788, 2789
A
B
C
E
E
K
2786
2787 2788
2789
L
H
M
G
F
K
N
D
P
Fig. 2
Fig. 1
