Quick-Start Guide
Product ID
CABSHELFV2U-16-RACK
CABSHELFV2U-12-RACK
CABSHELFV1U-16-RACK
FeatureFunction
1
Front Mounting
Brackets
• Used to fasten the to the of a ShelfMounting PostsServer
Rack
2Shelf Surface • Place Server Rack Equipment
3Ventilation Holes• Promote airow for the Server Rack Equipment
Package Contents
• 2-Post Vented Shelf x1
• M5 Cage Nuts x 4
• M5 Screws x 4
• Quick-Start Guide x 1
Vented 2-Post Shelf
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit:
www.StarTech.com/CABSHELFV2U-16-RACK
www.StarTech.com/CABSHELFV2U-12-RACK
www.StarTech.com/CABSHELFV1U-16-RACK
• Refer to the manufacturer of the Server Rack to determine the mounting hole type and
size
• Phillips head screwdriver
• Cage nut tool (Optional)
Warnings!
• Read the entire Quick-Start Guide and ensure the instructions are fully understood before
using this product.
• Before adding equipment to this product, ensure this product has been properly mounted.
• Never operate this product if parts are missing or damaged.
• Ensure the weight of the equipment does not exceed the weight capacity of this product. If
the weight capacity is exceeded, personal injury or damage to the equipment is possible.
• These product can support the following weight:
• CABSHELFV2U-16-RACK: 44lb / 20kg
• CABSHELFV2U-12-RACK: 25lb / 11.3 kg
• CABSHELFV1U-16-RACK: 30lb / 14kg
Installation
1. Identify a suitable location on the to mount the . The requires Server RackShelfShelf
2U 1U Mounting Space orof(depending on the model).
Note: The Server Rack should have enough Mounting Depth to accommodate the Shelf.
2. Install the (x 4) into the (x 4) on the of the M5 Cage Nuts Mounting HolesFront Posts
ServerRackCage Nut Tool . If available, use a or a preferred installation method to
install the . Cage Nuts
Note:If the Server Rack has M5 threaded holes, skip this step. The M5 Screws can be
installed without the M5 Cage Nuts.
Usethe manufacturer-recommended Screws for the Server Rack if they dier from M5.
3. Position the onto the at the chosen , determined inShelfServer Rack U Height
