Quick-Start Guide
Product ID
D130-DECIBEL-METER
Compact Decibel Meter - Range 30 to 130dB
Feature Function / Operation
1
Capacitive
Microphone with
Foam Wind-
Screen
• Captures Sound for Measurements
2LCD Display • Displays Settings and Measurement Information
3
Power On/O
Button
• Turns the Device On and O
4
Fast/Slow
Response Speed
Button
• Switches Between Fast and Slow Response Modes
5
Measuring Mode
(MAX/MIN)
Button
• Switches Between Maximum (MAX) and Minimum (MIN) Measuring
Modes
6
Hold & Back-
Light Button
• Holds Readings within the Current Timing Interval
• Turns LCD Display Back-Light On and O
7
Rear Battery
Compartment
• Houses Installed Batteries
Package Contents
• Decibel Meter x 1
• AAA Batteries x 3
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/D130-DECIBEL-METER
• Phillips Head Screwdriver (for battery installation)
*Product may vary from image
1
2
4
3
5 6
7
Quick-Start Guide
Battery Installation
1. Using a (not included) remove the screw from the Phillips Head Screwdriver
bottom of the , and remove the cover.Battery Compartment
Note: If used batteries are installed, remove them.
2. Install the included 3x AAA Batteries into the , as shown Battery Compartment
in .Diagram 1
3. Replace the cover, then using a (not included) Phillips Head Screwdriver
drive the screw (removed in Step 1) back into the hole at the bottom of the
Battery Compartment.
Operation
Turning the Device on and o
To turn the device on: Power On/O ButtonLong press the for 2 seconds, while
the device is powered o.
To turn the device o: Short press the Power On/O Button, while the device is
powered on.
Diagram 1
Diagram 2
Element Function
A
Battery Life
Indicator
• Displays at all times when the device is
powered on, indicating the battery usage
level
B
MAX or MIN
Indicator
• Displays when the device is in MAX or
MIN Measuring Mode
C
Decibel
Measurement
Reading
• Displays at all times when the device
is powered on, indicating noise
measurement detected in decibels (dB)
D
FAST, SLOW
or HOLD Mode
Indicator
• Displays when the specic mode
is activated, indicating the timing
interval in which the dB measurement
is displayed and if the current values
displayed are held
E
Out of Range Alert
• Displays when the measurement is less
than 30dB or more than 130dB
B
A
C
D
MAX/MIN Modes
MAX & MIN Modes are optional operation modes of the . While in MAX or MIN Decibel Reader
Modes the on the will display the loudest (MAX), Decibel Measurement Reading LCD Display
or quietest (MIN) measurements captured while in that specic mode. The values will refresh if a
louder or quieter measurement is detected while in the specic mode.
To toggle between MAX, MIN and Standard Modes: Short press the
Measuring Mode (MAX/MIN) Button.
LCD Display, Settings and Measurement Information
Refer to Image ( ) and the table LCD Display Diagram 2 Element/Function
to understand the settings and measurement information shown on the LCD
Display.
Standard Mode
Standard Mode is the default operation mode of the . While in Standard Mode, Decibel Reader
the on the will display the current sound reading.Decibel Measurement Reading LCD Display
FAST/SLOW Response Speeds
While in standard mode, the current sound reading will refresh values at FAST (125ms) or
SLOW (1s ) intervals, based upon user selection and preference.
To toggle between FAST and SLOW response speeds: Short press the
FAST/SLOW Response Speed Button.
Hold Mode
Hold Mode is an optional operation mode of the . While in Hold Mode the Decibel Reader Decibel
Measurement Reading LCD Displayon the will continuously display the sound reading that was
on the display when Hold Mode was activated.
To toggle in and out of Hold Mode: Hold & Back-Light ButtonShort press the .
Turning the LCD Display Back-Light
To turn the LCD Display Back-Light on and o: Hold & Back-Light Button Long press the for 2
seconds, while the device is powered on..
Additional Features
Power Alert
The power sign will display when the battery is critically low, indicating it is time to change
batteries.
Auto-O
The device will automatically power down if it’s not interacted with for 5 minutes.
E
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Crescent
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Road
Brackmills,
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Quick-Start Guide
BATTERY CAUTION:
Risk of explosion if battery is replaced with an incorrect type.
Dispose of used batteries according to the battery manufacturer’s instructions.
Safety Measures
EN: Do not touch the product under power if the product has an exposed printed circuit board or electrical wire.
Warning: please consult the online manual for detailed safety instructions.
NL: Raak het product niet aan als het onder stroom staat en er een blootliggende printplaat of elektrische draad zichtbaar is.
Waarschuwing: raadpleeg de online handleiding voor gedetailleerde veiligheidsinstructies.
FR: Ne touchez pas le produit lorsqu’il est sous tension et qu’il dispose d’un circuit imprimé ou d’un l électrique apparent.
Attention : veuillez consulter le manuel en ligne pour des instructions de sécurité détaillées.
DE: Berühren Sie das Produkt nicht unter Spannung, wenn es eine freiliegende Leiterplatte oder einen freiliegenden elektrischen Draht hat.
Warnung: Ausführliche Sicherheitshinweise nden Sie im Online-Handbuch.
IT: Non toccare il prodotto quando è sotto tensione se il prodotto ha una scheda di circuito stampato o un lo elettrico esposto.
Attenzione: consulti il manuale online per le istruzioni di sicurezza dettagliate.
ES: No toque el producto cuando se encuentre bajo tensión si este tiene una placa de circuito impreso o un cable eléctrico expuesto.
Advertencia: Para instrucciones detalladas de seguridad, consulte el manual en línea.
JP: プリント基板や電線が露出している製品は、電源が入っている状態で直接触れないでください 。
注意：安全性に関わる注意事項の詳細について、オンラインマニュアルを参照してください。
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies
not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party
company in question. StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of their respective holders
Warranty Information
This product is backed by a 2-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any
damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary
loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply
to you.
Regulatory Compliance
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a dierent circuit than the receiver.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the device. If shielded interface cables are included with the product, or if additional
components or accessories are designated for use with the installation, they must be used to ensure compliance with
FCC regulations.
ISED Statement / Déclaration d’ISED
CAN ICES-003(B) / NMB-003(B)
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
RCM
The information in this section applies to products bearing the Australia and New Zealand Regulatory Compliance
Mark (RCM):
This device equipment complies with the Australian and New Zealand regulatory approvals requirements.
Warning:
Class A products that may be utilized in domestic/residential environments may cause radio interference in which
case the user may be required to take adequate measures.
EU REACH Declaration
This product complies with the Registration, Evaluation, Authorization, and Restriction of Chemicals (REACH)
Regulation (EC) of the European Parliament and the Council. The product does not contain any of the Substances of
Very High Concern (SVHC) or Restricted Substances above the threshold values declared by the European Agency for
Chemicals (ECHA) on their website’s documented/maintained lists.
EU WEEE Directive
StarTech.com products must not be disposed of with household waste. StarTech.com products must be disposed of
at an authorized electrical and electronic equipment recycling facility. By collecting and recycling waste, you help
save natural resources and ensure that the product is disposed of in an environmentally friendly and healthy way.
EU CE EMC/EMI
StarTech.com hereby declares that this device complies with the Electromagnetic Compatibility Directive (EMC).
A copy of the EU Declaration of Conformity is available at www.startech.com under the Product Support tab.
www.startech.com/D130-DECIBEL-METER
EU CE RoHS Environmental
StarTech.com hereby declares that this product complies with the Restriction of Hazardous Substances (RoHS)
directive of the European Parliament and the Commission Delegated Directive (EU).
A copy of the EU Declaration of Conformity is available at: under the www.startech.com/D130-DECIBEL-METER
Product Support tab.
EU REACH Declaration
This product complies with the Registration, Evaluation, Authorisation, and Restriction of Chemicals (REACH)
Regulation (EC) of the European Parliament and the Council. The product does not contain any of the Substances of
Very High Concern (SVHC) or Restricted Substances above the threshold values declared by the European Agency for
Chemicals (ECHA) on their website’s documented/maintained lists.
