Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 8, 2019 3:44 PM

Product Diagram (ECUSB3S11)

ComponentFunction

1Express Card Port

• Used to connect the to the Express CardHost

Computer’s Express Card Slot.

Requirements

For the latest requirements, please visit . www.startech.com/ECUSB3S11

• An available ExpressCard port

• Microsoft® Windows® XP, Vista, 7, or 8 / Server 2003, or Server 2008 R2

Installation

Hardware installation

Note: Turning the computer o to insert/remove is not necessary as ExpressCard

they are hot-pluggable.

1. Slide the (card label side up) into an on the ExpressCard PortExpress Card Slot

Host Computer.

2. Push the into the , until it clicks and locks into Express CardExpress Card Slot

place.

3. To eject the , simply push the card further into the slot until it clicks, Express Card

and then release and it will then be automatically ejected from the slot.

1 Port Flush Mount SuperSpeed USB 3.0 ExpressCard

Notes: Some t loosely into an This has the ExpressCard/34 ExpressCard/54 Slot.

potential to cause movement and can result in accidental disconnection. A snap-on 34

mm to 54 mm stabilizer bracket is included for such installations.

Optional: For some high-powered USB 3.0 devices, additional power may be required.

Connect the USB to DC adapter cable from a USB port on the computer system to the

DC plug on the card. This will provide additional power to the USB 3.0 port.

Driver Installation

Windows XP/Server 2003/Vista/7/Server 2008 R2/8

1. Insert the included into the . Driver CDHost Computer’s CD/DVD Drive

Note: If the wizard appears on the screen, select or Found New HardwareCancel

close the window and do not install the drivers.

2. The will automatically launch, click to display the contents on the . If not, CDCD

open ( in XP) and double-click on the . ComputerMy ComputerCD/DVD

3. Enter the folder , then and click the le . USB 3.0 HostNECSetup.exe

4. This should launch the driver Installation wizard. Continue through the wizard and

once complete, all the necessary drivers will be installed.

Specications

Bus Interface

ExpressCard 2.0 USB 3.0 base specication 1.0 Intel xHCI

specication 0.95

Form Factor“Slim” ExpressCard/34 (34mm)

Chipset IDNEC/Renesas µPD720202

Connectors

1 x USB 3.0 type A female

1 x DC Power female (type A)

Maximum Data Transfer

Rate

USB 3.0: 5Gbps*

Operating Temperature0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature-10°C ~ 85°C (14°F ~ 185°F)

Humidity5% ~ 95% RH

Dimensions (LxWxH)75mm x 34mm x 5mm

Weight17.5g
