Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/29/2011

For the most up-to-date information, please visit: www.startech.com

IDE2CF

40/44 Pin IDE to Compact Flash SSD Adapter

*actual product may vary from photos

Packaging Contents

• IDE2CFadapter

• InstallationGuide

System Requirements

• Computersystemwithavailable40or44-pinIDEchannel

Installation

1. InserttheCompactFlashcardintotheCN2slotontheadapter.

2. Changethejumpersettingstomatchyourconguration.

3. Mounttheadapterinsideyourcomputercase.

4. Connecteitherthe40or44-pinIDEribboncablefromyourIDE

controllertotheappropriateconnectorontheadapter.

5. Connecttheoppypowerconnector(SP4)fromyourpower

supplytotheCN5connectorontheadapter.

• CN2–CompactFlashsocket(Master/Singlemode)

• CN3–40-pin(2.54mmpitch)IDEconnector

• CN4–44-pin(2.0mmpitch)SFFIDEconnector

• CN5–Floppydiskdrivepowerconnector

• LED1–CompactFlashcard-detectindicator

• LED2–Read/Writeactivityindicator

• LED3–Power-onindicator

Jumper Settings

JP1–CompactFlashpowersourceselection:

1-2 * Externalpower(CN5)or44-pinSFFIDEconnector(CN4)

2-3

Pin20of40-pinstandardIDEconnector(CN3),forVIA

EPIAseriesmotherboards

JP2–CompactFlashvoltageselection:

1-2 * +5.0V

2-3 +3.3V

JP3–CompactFlashmodeselection:

1-2 * Master/Single

2-3 Slave

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

Bus Interface ATA

Connectors

40-pinIDE,

44-pinIDE,

SP4oppypower,

CFcardslot

LED Indicators

Power,

CardDetect,

Activity

CompactFlash
