Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: February 27, 2019 9:51 AM

Product Diagram (M2E1BMU31C)

Exterior

ComponentFunction

1Drive-Tray Screws x 2

• Used to secure the in the Drive Tray

Enclosure.

2Power LED• Indicates that the Enclosure is receiving power.

3USB-C Port

• Used to connect the to the Enclosure Host

Computer.

Interior

ComponentFunction

4Drive Connector• Used to connect the to the .DriveEnclosure

5

Adjustable Drive

Length Holes

• Used to accommodate dierent drive lengths.

6

Drive-Mount Screw/

Nut

• Used to secure the to the .DriveEnclosure

M.2 NVMe Enclosure | USB 3.1 (10Gbps) | USB-C

1

Requirements

For the latest requirements and full manual, please visit www.startech.com/

M2E1BMU31C

Installation

Installing a Drive

Warning! Drives should be handled carefully, especially when they’re transported. If

you’re not careful with your drives, you may lose data as a result.

1. Using a remove the (x 2) from the Phillips Head Screwdriver,Drive-Tray Screws

Enclosure Cover Plate and remove the.

2. Carefully pull the out of the . Drive TrayEnclosure

3. Place the next to the and align the screw groove on the with DriveDrive TrayDrive

the on the .Adjustable Drive Length HolesDrive Tray

Note: If the drive-mount hardware is already installed in the correct position, proceed

to step 6.

4. Use a (included) and a set of to remove the Phillips Head Screwdriver PliersDrive-

Mount Screw, Stando,Nut and .

5. Insert the and into the correct (80, 60, StandoNutAdjustable Drive Length Hole

42, or 30) according to the length of the .Drive

6. Using a set of tighten the and .PliersStandoNut

7. Gently slide the connector on the (on a 30-degree angle) into the Drive

corresponding connector on the .Enclosure

Note: The connector on your drive is keyed so that it only ts one way.

8. Lightly push the down into position on the circuit board.Drive

9. Insert the through the screw groove on the and into the Drive-Mount ScrewDrive

Stando.

10. Using a tighten the , being careful Phillips Head ScrewdriverDrive-Mount Screw

not to over-tighten.

11. Slide the into the center grooves in the enclosure so that the Drive TrayUSB-C Port

is facing outward.

12. Place the over the and circuit board.Cover PlateUSB-C Port

2

4

3

6

5
