Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 14, 2020 1:26 PM

Product Diagram (PEXUSB312A3)

ComponentFunction

1USB-A Ports

• Used to connect a to USB Peripheral Device

the. USB Card

2Bracket Screws

• Used to theorSecure Low Prole Full Prole

Bracket USB Card.to the

3PCI Express Connector

• Used to connect the to the USB CardPCI

Express SlotHost Computer on the .

4SATA Power Connector

• (Optional) Connect a 15 Pin SATA Power

ConnectorUSB to provide extra power to the

Type-A Ports.

Requirements

For the latest requirements, please visit www.startech.com/PEXUSB312A3

• Computer with an available PCI Express® slot (x4, x8, or x16)

• (Optional) SATA Power Source

Tools

• Small Phillips® Head Screwdriver

2-Port USB 3.1 Card | 10Gbps per port | 2x USB-A | PCIe

Hardware Installation

Installing the Low Prole Bracket

By default the is attached to the . Depending on your Full Prole BracketUSB Card

system conguration you may need to remove the and replace it Full Prole Bracket

with the (included).Low Prole Bracket

1. Using a (sold separately), remove the two Small Phillips Head Screwdriver Bracket

ScrewsFull Prole BracketUSB Card securing the to the .

2. Align the on the with the on the Screw HolesUSB CardScrew HolesLow Prole

BracketUSB CardScrew HolesLow . Making sure the is sitting on top of the on the

Prole Bracket.

3. Insert the through the and into the on the Bracket ScrewsUSB CardScrew Holes

Low Prole Bracket.

4. Using the , tighten the being Small Phillips Head ScrewdriverBracket Screws,

careful not to over-tighten.

Installing the USB Card

Warning: USB cards can be damaged by static electricity. Make sure that you are

properly grounded before you open the computer case or touch the . You USB Card

should wear an anti-static strap when you install any computer components. If an

anti-static strap is not available, discharge any built-up static electricity by touching

a large grounded metal surface for several seconds. Only handle the by its USB Card

edges and do not touch the gold connectors.

1. Turn o the and disconnect any that are HostComputerPeripheral Devices

connected (e.g. printer, external hard drives, etc.).

2. Unplug the from the back of the .Power CableHost Computer

3. Remove the from the . CoverHost Computer’s Case

Note: Consult the documentation that came with the for details Host Computer

about how to remove the safely.Cover

4. Locate an open (x4, x8, or x16) and remove the corresponding PCI Express Slot

Metal Cover PlateHost Computer’s Case from the back of the .

5. Gently insert the into the open and fasten the USB CardPCI Express SlotBracket

to the back of the .Host Computer’s Case

6. (Optional) Connect a from the to the 15 Pin SATA Power ConnectorPower Supply

SATA Power ConnectorUSB Card on the .

2

1

3

4
