Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: May 15, 2019 2:18 PM
Product Diagram (SM21BMU31CI3)
Exterior
ComponentFunction
1Drive-Tray Screws x 2
• Used to secure the in the Drive Tray
Enclosure.
2USB-C Cable
• Used to connect the to the Enclosure Host
Computer.
Interior
ComponentFunction
1
M.2 NGFF B Key Drive
Connector
• Used to connect the to the .DriveEnclosure
2
Drive Length Holes
(x 2)
• Used to accommodate dierent drive lengths
(42 mm, 60 mm and 80 mm).
3
Drive-Mount Screw/
Nut
• Used to secure the to the .DriveEnclosure
M.2 NGFF SATA Enclosure | USB-C | USB 3.1 (10Gbps)
1
4
Stando (not
displayed)
• Used to secure the to the DriveEnclosure
using either the 42 mm or 60 mm Drive
Length Holes.
Requirements
For the latest requirements, please visit www.startech.com/SM21BMU31CI3
• An available USB-C Port
• An M.2 NGFF SATA SSD
Installation
Installing a Drive
Warning! Drives should be handled carefully, especially when they’re transported. If
you’re not careful with your drives, you may lose data as a result.
1. Use a (included) to remove the (x 2) Phillips Head Screwdriver Drive-Tray Screws
from the . Enclosure
2. Carefully pull the out of the . Drive TrayEnclosure
3. Place the beside the and align the screw groove on the with DriveDrive TrayDrive
the on the .Adjustable Drive Length HolesDrive Tray
4. Use a to remove the .Phillips Head Screwdriver Drive-Mount Screw
Note: If the drive-mount hardware is already installed in the correct position, proceed
to step 9.
5. Align the with the correct according to the length of Stando Drive Length Hole
the .Drive
6. Insert the into the large part of the .StandoDrive Length Hole
Note: Make sure that the longer part of the stando is on the same side as the M.2
NGFF B Key Drive Connector.
7. Align the notches on the with the edges of the smaller part of the StandoDrive
Length Hole.
8. Slide the into the smaller part of the .Stando Drive Length Hole
9. Gently slide the connector on the (on a 30-degree angle) into the DriveM.2 NGFF B
Key Drive ConnectorEnclosure on the .
Note: Do not force the Drive into the enclosure, the connector on your drive is keyed so
that it only ts one way.
2
1
2
3
