Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 20, 2021 3:03 PM
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (SM2E1BMU31C)
Exterior - Enclosure
ComponentFunction
1Drive-Tray Screws x 2
• Used to secure the in the Drive Tray
Enclosure.
2Power & Activity LED
• Indicates that the is receiving Enclosure
power.
• Blinks during read/write activity.
3USB-C Port
• Used to connect the to the Enclosure Host
Computer.
Interior - Drive Tray
ComponentFunction
4Drive Connector• Used to connect the to the .DriveEnclosure
5
Adjustable Drive
Length Holes
• Used to accommodate dierent drive lengths.
6
Drive-Mount Screw/
Stando/Nut
• Used to secure the to the .DriveEnclosure
M.2 SATA/NVMe SSD Enclosure - USB 3.2 (10Gbps) w/ USB-C and USB-A Cables
Package Contents
• M.2 SSD Enclosure x 1
• USB-C to USB-C Cable x 1
• USB-A to USB-C Cable x 1
• Drive Installation Screw Kit x 1
• Micro Screwdriver x 1
• Quick-Start Guide
Product Information
For the latest requirements, please visit
www.startech.com/SM2E1BMU31C
Product Requirements
• M2 SATA/NVMe SSD x 1
• 30 mm, 42 mm, or 60 mm Drive Length
• Needle-nose Pliers x 2
Installation
Installing a Drive
Warning! Handle drives with care.
1. Remove the (x 2) from the , using a Drive Tray ScrewsEnclosurePhillips Head
Screwdriver Cover Plate, and remove the.
2. Carefully pull the out of the . Drive TrayEnclosure
3. Remove the , using a .Drive-Mount ScrewPhillips Head Screwdriver
4. Place the next to the and align the screw holes in the with DriveDrive TrayDrive
the on the to determine the desired Adjustable Drive Length HolesDrive Tray
Adjustable Drive Length Hole setting.
Note: If the drive mounting hardware is already installed in the correct position,
proceed to step 8.
5. Remove the and , using two sets of Drive StandoNutNeedle-nosePliers.
6. Insert the and into the (60, 42, DriveStandoNutAdjustable Drive Length Hole
or 30) according to the length of the .Drive
7. Tighten the and , using two sets of StandoNutNeedle-nosePliers.
1
2
3
4
6
5
