Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 03/27/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xVS122HDMIUswitch

• 1xHDMIcable

System Requirements

• HDMIenableddisplaydevice(i.e.HDTV,monitor,projector,etc.)

• HDMIenabledvideosources(i.e.computer,gameconsole,etc.)

VS122HDMIU

2 Port Auto High Speed HDMI Switch

*actual product may vary from photos

Installation

1. ConnectanHDMIcable(notincluded)fromeachofthevideo

sourcedevices(i.e.computer,gameconsole,DVR,etc.)tothe‘IN’

connectorsonthevideoswitch.Port1istheprimaryinputsowill

bedisplayedbydefault.

2. ConnectanHDMIcablefromthedisplaydevice(i.e.HDTV,

monitor,etc.)tothe‘OUT’connectoronthevideoswitch.

3. Turnonthedisplaydevice,followedbythevideosources.

IfthevideosignalonPort1isterminated(i.e.turnedo,cable

disconnected,etc.),thenthevideoswitchwillautomaticallyselect

Port2.OncethevideosignalisrestoredonPort1,thevideoswitch

willautomaticallyswitchbacktoPort1.

Thevideoswitchcanbemanuallytoggledbetweenportsby

pressingthe“Select”buttononthetopoftheunit.Thissettingwill

remainuntilthevideosignalonPort1changes,settingitbackto

automaticmode.

HDMIVideoSources DisplayDevice

Specications

Video Signal HDMI(1.3)

Number of Ports 2

Connectors 3xHDMItypeAfemale

LEDs 1xPower

2xPortSelectionIndicator

Video Bandwidth 2.5Gbps

Maximum Video Resolution 1080p

Maximum Cable Distance 10m

Audio Support Yes

HDCP Compliant Yes(HDCP1.1)

Power Adapter Self-powered

Operating Temperature 0°C~70°C(32°F~158°F)

Storage Temperature -65°C~150°C(-85°F~302°F)

Humidity 10%~85%RH

Dimensions 63.0mmx59.0mmx15.0mm

Weight 35g

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSA LLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
