INSTRUCTIONS AND
RECOMMENDATIONS FOR THE USE,
INSTALLATION AND MAINTENANCE OF
BUILT-IN GAS COOKTOPS
Dear customer,
Thank you for buying one of our products.
We are sure that this new, modern, functional and practical appliance, made using the finest quality
materials, will fully satisfy your requirements. This new appliance is very easy to use, but in order to
obtain the best results, we strongly recommend that you read this booklet carefully before use.
These instructions are valid exclusively for countries indicated on the label of the appliance.
The manufacturer cannot be considered responsible for any damages to people or to things in the
event of incorrect installation or improper use of the appliance.
Felix Storch, Inc.
Summit Appliance Division
An ISO 9001:2008 registered company
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
MODEL: GC22SS
The Manufacturer cannot be held responsible for any imprecision due to printing or copying errors
contained in this booklet. The figures shown are purely indicative. We reserve the right to make any
changes to our products which we consider to be necessary or useful, also in the interest of the user,
without affecting their essential characteristics in terms of functionality and safety.
This cooktop was designed to be used exclusively as a cooking appliance: any other use (such as
heating rooms) is to be considered improper and dangerous.
COD. 04037GT - 11.06.2015
2
TABLE OF CONTENTS
Important Safeguards .......................................................................... 3
Location of Parts ................................................................................. 4
Installation.....................................................................................5 - 6
Installing the Cooktop. ................................................................ 5
Sealing the Cooktop. .................................................................. 6
Room Ventilation. ........................................................................ 6
Gas Connection. ......................................................................... 7
Electrical Connection. ................................................................. 8
Adjustments ......................................................................................... 9
Conversions .................................................................................. 10-11
Using the Cooktop .............................................................................. 12
Lighting the Burners................................................................... 12
Proper Use of the Burners. .................................................. 12-13
Cleaning .............................................................................................. 14
Servicing. ............................................................................................ 15
Replacing Components
Limited Warranty................................................................................ 16
3
IMPORTANT SAFEGUARDS
1) SAFETY INSTRUCTIONS
For all appliances:
● The product shall be installed according to the statement that the installation must conform with local
codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54.
● The product must be electrically grounded in accordance with local codes or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70.
● The appliance and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa). The maximum
gas supply pressure is 4 inch WC and 11 inch WC and the gas pressure regulator provided is regulated
to 1 inch water column above the manufacturer‟s specified manifold pressure.
● Always disconnect all cord-connected appliances before servicing. Appliances shall include
instructions relative to location of the wall receptacle and a warning to the user to disconnect the
electrical supply before servicing the appliance.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
● Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2) WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor‟s phone.
Follow the gas supplier‟s instructions.
- If you cannot reach your gas supplier, call the fire department.
● Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
● Save any nozzles removed from the appliance for future use.
● The maximum depth of cabinets installed above the cooktop should be 13 inches (330 mm).
● Keep the appliance clear and free from combustible materials, gasoline and other flammable vapors
and liquids.
● Do not obstruct the flow of gas or block any air vents.
