LOCATION OF CONTROLS

1.Telescopic antenna

2.Dial scale

3.Built-in speaker

4.Volume control and Power

ON/OFF knob

5.Phones jack

6.Battery compartment

7.Band switch

8.Tuning knob

9.Power on indicator

MODEL RP-S1

POCKET RADIO

8

4

29

7

5

6

3

1

TELESCOPIC ANTENNA

1.For FM band extend the telescopic rod antenna fully inorder to obtain

the best reception.

2.For AM band reception, the unit is equipped with a built-in ferrite bar

antenna.

For optimum reception, it may be necessary to rotate the unit until clear

reception is received.

PHONE JACK

For private listening connect an earphone (included) with a 3.5mm plug to the

phone jack. The built-in speaker will be automatically disconnected.

NOMINAL SPECIFICATIONS

Frequency Range:FM 88-108 MHz

AM 540-1600 kHz

Dimensions:100(L) x 52(W) x 18(D) MM

Weight:60 g

Power supply:DC3V (AAA/LR03x2

Batteries - not included)

Weight and dimensions are approximate because we continually strive to

improve our products, specifications may change without prior notice.

POWER SUPPLY

Insert 2 AAA size batteries into the battery compartment at the back of the

unit, make sure they are connected according to the proper polarity.

OPERATION

1.Switch on the unit by rotating the Volume control/Power ON/OFF knob

clockwise. Adjust the Volume control to comfortable listening level.

2.Set the Band switch to the desired radio band FM or AM.

3.Turn the Tuning knob to the desired station.

4.To turn the radio off, rotate the Volume control/Power ON/OFF knob

anti-clockwise until a slight click sound is heard.

You can help protect the environment!

Please remember to respect the local regulations: hand

in the non-working electrical equipments to an appropriate

waste disposal center.

Sunstech RP-S1 (English).p652006/11/8, ¤U¤È 05:371
