UNLOCK
Remove Track Joiners
1
Lift open both Track Locks and pull out the
Track Joiners.
The Track Joiners are only required when
joining multiple tracks together.
Before you start filming, there are a few simple steps
to follow to ensure your Magic Carpet PRO is
assembled correctly and you’re sliding smoothly.
This guide will walk you through the correct Magic
Carpet Pro set up, as well as some helpful tips.
Setup Guide
Additional resources can be found at
support.syrp.co.nz
Install the Carriage
2
Slide the Carriage on to the Track Rails.
Ensure you lock the carriage
once installed and when not
in use.
Orientate the carriage with
the Carriage Lock on the
same side as the Flywheel
Tread!
Carriage
Lock
Flywheel
Tread
LOCK
Install the End Caps
3
Unlock both the Track Locks and insert the
End Caps.
Close the Track Locks securing the End
Caps in place.
Insert evenly with the
End Caps flush with the
Track Ends.
LOCK
UNLOCK
Remove the Quick Release Plate
5
Slide the Quick Release Lock to unlock and
push in while pulling the Plate up to remove.
PUSH IN
FIRMLY TO
UNLOCK
Adjust the Legs
4
Lift open the Leg Locks to release the legs
and set the leg angle.
Fine leg adjustment can be
achieved by twisting the
foot.
LOCK
UNLOCK
WARNINGS
Aways lock the Carriage when not in use and
transporting the Track.
Do not lift the Track by your camera or attached
accessory. Always detatch camera and
accessory before transporting.
Every 3 feet length of Track should be supported
by a tripod or other support, to add rigidity and
prevent sag.
!
!
!
CARE AND MAINTENANCE
To maintain optimal smooth movement regularly
wipe the Carriage Wheels and Track clean with a
soft cloth to remove dirt.
Avoid over tightening the Tension Wheel, doing so
could damage the track.
Fasten Quick Release Plate
6
Screw the Quick Release Plate to your video
head.
Pull the Thread Release to
swap between 1/4” & 3/8”
Camera Screws.
PULL
TO RELEASE
SWAP
Mount Camera
7
Push the Quick Release Plate down into the
carriage. You will hear a click when it’s flush
and engaged. Slide the Quick Release Lock
to lock.
Ensure the Quick Release
Plate is always locked in
place once installed.
!
The Tension Wheel is
pre-calibrated. Adjust
only enough to remove
slop - don’t over tighten.
Engage Flywheel
8
Press the Flywheel button in to engage or
release the Flywheel.
PRESS
F
L
Y
W
H
E
E
L
Extend Track Length (optional)
9
Lift open the Track Locks and insert the
Track Joiners. Close the Track Locks.
Open the Track Locks on the additional
Track and insert over the Joiners. Close the
Track Locks.
IMPORTANT
Align the Flywheel Tread
of both Tracks.
!
LOCK
UNLOCK
Align the Track Joiner
channel with the pin
inside the Track and
insert fully (half of the
Track Joiner).
Counter Weight Camera (optional)
10
Tie a counterweight rope to the Counter-
weight Loop and thread over the green
Counterweight Roller. Tie the end to a
counterweight.
Add counterweight equal to
your camera rig and the
carriage (1.6kg / 3.5lbs).
Kg
Counterweight
Roller
Counterweight
Loop
IMPORTANT
Do not lift the Track
by your camera or
attached accessory.
!
