TA-25Mini v.2

CUSTOM INSTALL INTEGRATED AMPLIFIER

Instruction manual

Edition 05-2023

Introduction

Thank you for purchasing this TAGA Harmony amplier.

TAGA Harmony TA-25Mini v.2 is an efcient, cost-effective choice for home and commercial installations in restaurants, pubs, shops, conferencing rooms,

tness clubs for background music playback.

It is ideal for simple installations or as a part of big installations.

It delivers pure and distortion-limited power as well as rich sound performance with stunning accuracy, soundstage and dynamics.

KEY FEATURES:

• Efcient power supply (24V, 3A) and Class D amp provide . high power 2 x 50W at 4ohm

• Easy placement thanks to small dimensions and weight.

• Rack handles.

• Low working temperature and an external power adaptor allows for placement in closed areas (for example in ceilings or walls).

• 2 analog stereo inputs (connected in parallel) RCA and 3.5 mm.

• Preamplier output dedicated for an optional external power amplier, a powered subwoofer or active speakers.

• Limiter to prevent clipping.

Cleaning
