Installation and User Manual

Product:

TJM Pro Series Single Air Compressor

Vehicle:

Generic

Part No.

013COMPVPROSAA

For product warranty please refer to our website www.tjm.com.au

File: F-17800.docx

Page 1 of 20

08/02/2023

• Before commencing fitment read instructions and ensure all listed components are supplied.

• It is a condition of the warranty that the product has been correctly installed by suitably qualified

personnel and is used in accordance with accompanying instructions where provided. For product

warranty please refer to our website www.tjm.com.au

• Estimated Fitting Time: 2 hrs

• Treat any holes drilled into the vehicle body with rust preventative paint.

• Holes drilled for cable routing should have a suitable sized rubber wiring grommet installed. This will

prevent damage to the cables.

• Always place the product on a soft workspace to prevent damage prior to installation.

• Do not mount compressor below the water-wading line of the vehicle. Refer to the vehicle manufacturer

for this specification.

• Compressor surface becomes very hot during operation. Mount away from flammable materials and

avoid locations where it may be accidently touched while operating.

• Rated for 12 V DC systems only.

• Images are for reference only and may vary slightly from actual product.

TJM Pro Series Single Air Compressor: Installation and User Manual
For product warranty please refer to our website www.tjm.com.au
File: F-17800
Page 2 of  20
08/02/2023


Table of Contents

0  Compressor Specifications...................................................................................................................... 3
1  Exploded View ..................................................................................................................................... 3
2  Bill of Materials ................................................................................................................................... 3
3  Electrical Specification ........................................................................................................................ 4
4  Performance ........................................................................................................................................ 4
5  Hardware and Fittings ......................................................................................................................... 4
6  Recommended Fastener Torque Settings........................................................................................... 4
0  Compressor Assembly ............................................................................................................................ 5
1  Accessory Installation ......................................................................................................................... 5
2  Air Filter Installation ............................................................................................................................ 6
0  Vehicle Mounting .................................................................................................................................... 7
1  Mounting Location .............................................................................................................................. 7
2  Compressor Mounting ........................................................................................................................ 8
3  Securely Mounting the Compressor ................................................................................................... 9
0  Wiring the Compressor System ............................................................................................................ 10
1  Electrical Diagram ............................................................................................................................. 10
2  Connecting Wiring System ................................................................................................................ 12
3  Mounting Actuator Switches ............................................................................................................ 13
0  Post- Installation Examination .............................................................................................................. 14
1  Leak Testing ....................................................................................................................................... 14
2  Post installation checklist .................................................................................................................. 14
3  Post Installation notes: ..................................................................................................................... 15
0  Operating Instructions .......................................................................................................................... 16
1  Pro Locker Activation ........................................................................................................................ 16
2  Tyre Inflation ..................................................................................................................................... 16
3  Safety information ............................................................................................................................ 16
4  Operation Guide ................................................................................................................................ 17
0  Maintenance ......................................................................................................................................... 19
1  Routine Maintenance........................................................................................................................ 19
2  Troubleshooting Guide ..................................................................................................................... 19
3  Serviceable Components .................................................................................................................. 20
