Használati útmutató TRENDnet TV-HP400
Olvassa el alább 📖 a magyar nyelvű használati útmutatót TRENDnet TV-HP400 (16 oldal) a hangszóró kategóriában. Ezt az útmutatót 6 ember találta hasznosnak és 3.5 felhasználó értékelte átlagosan 4.1 csillagra
Oldal 1/16

TV-HW400 Wall Mount
TV-HN400 Corner Mount
TV-HP400 Pole Mount
TV-HC400 Ceiling Mount
06.06.2014

TV-HN400 Corner Mount
ŸQuick Installation Guide
ŸWall mount bracket
ŸCorner adapter
ŸMounting accessories
Package Contents
1. Before You Start
1
TV-HW400 Wall Mount
ŸQuick Installation Guide
ŸWall mount bracket
ŸMounting accessories
TV-HC400 Ceiling Mount
ŸQuick Installation Guide
ŸCeiling mount bracket
ŸMounting accessories
TV-HP400 Pole Mount
ŸQuick Installation Guide
ŸWall mount bracket
ŸPole adapter
ŸPole mount hoops
ŸMounting accessories
Note:
ŸFor masonry walls, the included expansion screws must be used to secure the wall mount.
ŸFor wood/metal stud walls, self-tapping screws (not included) can be used to secure the wall
mount without the use of expansion screws.
ŸMasonry walls must be thick enough to install expansion screws.
ŸEnsure that the wall is strong enough to withstand more than 8 times the weight of the IP
camera and the mount.

2
2. TV-HW400 Wall Mount
Components
Wall Mount Bracket
5 expansion screws with nuts and washers
1. Place the arm bracket at mounting location and use it to mark screw hole locations.
2. Mark Ethernet cable hole location.
Optional: The Ethernet cable (and other cables) can be run through the indentation at the
bottom of the mounting bracket. For this installation, there is no need to mark an Ethernet
cable hole.
Mounting Accessories
Mounting
3. Drill screw holes in the wall according to the holes of the mount and a hole for cables
(optional), and then insert expansion screws into the mounting holes.
Termékspecifikációk
Márka: | TRENDnet |
Kategória: | hangszóró |
Modell: | TV-HP400 |
