MS337
Business Efficiency and Profitability
Unitech’s innovatively designed MS337 2D rugged image scanner
provides for greater business efficiency, reading accuracy and productivity
with its fast 2D scanning engine and highly aggressive performance. Its
LED flash has virtually no repeated scanning making it highly efficient and
competitive in its class by reducing costs and maximizing uptime and
limiting downtime. The MS337’s Industrial standard miniature form factor
and rugged design provide for a compatible and durable technology.
Enhanced Efficient Technology
Unitech’s MS337 image scanner offers true Omni-directional 2D area
scanning technology with its high resolution integrated illumination mega
pixel image sensor and wide-angle lens designed to cover a large scanning
area to meet industry demand with its enhanced technology offering
precision and accuracy, reducing power consumption and increasing
efficiency. The MS337 provides a leading Industrial decoding software
package offering aggressive performance precision with its unmatched
decoding capability.
Highly Reliable and Flexible Technology
The MS337 provides easy firmware upgrades of new features and is ideal
for hand-free or self-service applications with no need for additional
hardware triggers. The MS337 is the one device for both indoor and
outdoor use in either absolute darkness or direct sunlight making it a
highly versatile scanner. Unitech also provides comprehensive IT support
packages and service along with its Windows based software platform.
Integrated Precision Performance
The Unitech MS337 accurately decodes even the most comprehensive sets of
symbologies with greater precision, which includes damaged, poorly printed or
wrinkled documents effectively. The MS337 is easily integrated with existing
applications utilizing the latest state of the art CMOS technology offering
unparalleled flexibility for customization and easy configuration with its
PC-based software. The MS337 scanning technology also provides greater
accuracy in multiple industry application including Passports, book ISBN,
license plates, ID cards, Bank Checks, pharmaceuticals management and Parts
management
Features
FirstFlash™ with integrated illuminationSwiftDecoder™ decoding software
Industrial standard miniature form factor
Image transfer (beta software available)
USB interface
3 - 5.5 VDC power input1D, 2D and OCR (option)
High-resolution image transfer
2D Image
Scanner
Operational
Image sensor CMOS, 1.23 mega pixel
Decode Capability All standard 1D and 2D symbologies
Illumination 650 nm LED
Aiming 615 nm LED
Environmental
Operating Temperature 0 º C ~ 40 º C (32 º F ~ 104 º F)
Storage Temperature -20 º C ~ 70 º C (-4 º F ~ 158 º F)
Humidity 0% - 95% relative humidity,
non-condensing
Light Levels 0 - 100,000 lux
(total darkness - direct sunlight)
Shock 7 G over 10 - 500 Hz
Drop Designed to whistand repeated 1.5 m (5’)
drops to concrete floors when mounted
inside a scanner case.
Mechanical
Dimensions 100 mm (L) x 70 mm (W) x 180 mm (H)
Weight 200 g w/o cable, 300 g with cble
Scan Performance
Depth of Field 25 mm – 310 mm, (1 - 12.2”) for 100% UPC
Width of Scan Field 118 mm (w) x 86 mm (h) (4.7” w x 3.5” h)
@ 127mm (5”);
237 mm (w) x 172 mm (h) (9.3” w x 6.8” h)
@ 254 mm (10”) from engine face
Minimum Element Width, 1D
0.102 mm (4 mil)
Width, 2D
0.191 mm (7.5 mil), Data Matrix
Resolution 1280 x 960 pixels
Print Contrast 20% minimum reflectance difference
Scan Pattern Area
Focal Point 100 mm (3.94”) from the imager face
View Angles 50° (horizontal), 37.5° (vertical)
MS337
04/ 09 REV. B
(mm) 0
(0”)
50
(2”)
100
(4”)
150
(6”)
200
(8”)
250
(10”)
Bar Code Minimum Element
0.127 mm (5 mil) 1D
0.254 mm (10 mil) 1D
0.330 mm (13 mil) 1D
0.127 mm (5 mil) PDF
0.254 mm (10 mil) PDF
0.254 mm (10 mil) DataMatrix
0.381 mm (15 mil) DataMatrix
0.508 mm (20 mil) DataMatrix
OCR-B (size 1; MRZ)
300
(12”)
350
(14”)
Scan Ranges
Specifications subject to change without notice. Copyright 2010 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
All product and company names are trademarks, service marks, or registered trademarks of their respective owners.
Unitech America
Los Angeles, Houston
http://us.ute.com e-mail: info@us.ute.com
http://can.ute.com info@can.ute.com
Mexico
http://latin.ute.com e-mail: info@latin.ute.com
Unitech Asia Pacific & Middle East
Taipei
http://apac.ute.com info@apac.ute.com / info@india.ute.com
http://mideast.ute.com info@mideast.ute.com
Unitech Japan
Tokyo
http://jp.ute.com e-mail: info@jp.ute.com
Unitech Europe
Tilburg / Netherlands
http://eu.ute.com e-mail: info@eu.ute.com
Unitech Greater China
Beijing, Shanghai, Guang Zhou, Xiamen
http://cn.ute.com info@cn.ute.com
Taipei http://tw.ute.com info@tw.ute.com
Head Office
Taipei
http://www.ute.com e-mail: info@hq.ute.com
