USER AND INSTALLER MANUAL

INSTALLER: READ THESE INSTRUCTIONS

SAVE THEM FOR USER

1107074 rev. C

VB0359

VB0360

www.venmar.ca/register-your-product.html or

www.vanee.ca/en/register-your-product.html

For additional information, visit venmar.ca or vanee.ca

A180H75rT*

A180E75RT*

A230H75RT* A230H75RS*

A210E75RT* A210E75RS*

v180H75rT*

V180E75RT*

V230H75RT* V230H75RS*

V210E75RT* V210E75RS*

Venmar Ventilation ULC, 550 Lemire Blvd., Drummondville, Québec, Canada J2C 7W9 venmar.ca / vanee.ca 800-567-3855

*THese producTs eArned THe enerGY

sTAr

bY meeTinG sTricT enerGY efficiencY

Guidelines seT bY nATurAl resources cAnAdA

And THe us epA. THeY meeT enerGY sTAr

requiremenTs onlY wHen used in cAnAdA.

Please take note that this manual uses the following symbols to emphasize particular information:

Identies an instruction which, if not followed, might cause serious personal injuries including possibility of

death.

CAUTION

Denotes an instruction which, if not followed, may severely damage the unit and/or its components.

NOTE: Indicates supplementary information needed to fully complete an instruction.

LIMITATION

For an installation and use in Canada only. Intended for a building on which Part 9 of division B from the effective version

ot the National Building Code of Canada applies with additional restrictions and exception (see page 25 for more details).

Installation work and electrical wiring must be done by a qualied person in accordance with all applicable codes and

standards, including re-rated construction codes and standards.

⚠WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSON(S) OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer.

2. Before servicing or cleaning this unit, disconnect power cord from electrical outlet.

3. This unit is not designed to provide combustion and/or dilution air for fuel-burning appliances.

4. When cutting or drilling into a wall or ceiling, do not damage electrical wiring and other hidden utilities.

5. Do not use this unit with any solid-state speed control device other than those specied in section 3.1.

6. This unit must be grounded. The power supply cord has a 3-prong grounding plug for your personal safety. It must be

plugged into a mating 3-prong grounding receptacle, grounded in accordance with the national electrical code and local

codes and ordinances. Do not remove the ground prong. Do not use an extension cord.

7. Do not install in a cooking area or connect directly to any appliances.

8. Do not use to exhaust hazardous or explosive materials and vapors.

9. When performing installation, servicing or cleaning this unit, it is recommended to wear safety glasses and gloves.

10. When applicable local regulation comprises more restrictive installation and/or certication requirements, the

aforementioned requirements prevail on those of this document and the installer agrees to conform to these at his own

expenses.

CAUTION

1. To avoid prematurely clogged lters, turn the unit OFF during construction or renovation.

2. Please read specication label on product for further information and requirements.

3. Be sure to duct air outside – Do not intake/exhaust air into spaces within walls or ceiling or into attics, crawl spaces, or

garage. Do not attempt to recover the exhaust air from a dryer or a range hood.

4. Do not run any air ducts directly above or within 2 ft (0.61 m) of a furnace or its supply plenum, boiler, or other heat

producing appliance. If a duct has to be connected to the furnace return plenum, it must be connected 10’ (3.1 m) away

from plenum’s connection to the furnace.

5. The ductwork is intended to be installed in compliance with all applicable local and national codes.

6. When leaving the house for a long period of time (more than two weeks), a responsible person should regularly check

if the unit operates adequately.

7. If the ductwork passes through an unconditioned space (e.g.: attic), the unit must operate continuously except when

performing maintenance and/or repair. Also, the ambient temperature of the house should never drop below 18°C

(65°F).

8. At least once a year, the unit mechanical and electronic parts should be inspected by qualied service personnel.

9. Do not use your unit during construction or renovation of your house or when sanding drywall. Certain types of dust

and vapors may damage your system.

10. Make sure at all times that the outside intake and exhaust hoods are free from any snow during the winter season. It

is important to check your unit during a big snow storm, so it doesn’t draw in any snow. If this is the case, please turn

the unit OFF for a few hours.

11. Since the electronic control system of the unit uses a microprocessor, it may not operate correctly because of external

noise or very short power failure. If this happens, unplug the unit and wait approximately 10 seconds. Then, plug the

unit in again.

12. Do not make excessive use of fragrance appliances or chemicals since some may damage the unit components material.

⚠WARNING

TABLE OF CONTENT

1. TECHNICAL DATA ...............................................................................................................4

1.1 AIR DISTRIBUTION (NORMAL OPERATION) .............................................................................................4

2. INSTALLATION ....................................................................................................................4

2.1 LOCATING AND MOUNTING THE UNIT .....................................................................................................4

2.2 INSTALLING THE DUCTWORK AND THE REGISTERS .............................................................................6

2.2.1 Fully DucteD SyStem (t-1) (thiS conFiguration allowS recirculation moDe to operate.) ............................6

2.2.2 exhauSt DucteD SyStem (t-2) (thiS conFiguration allowS recirculation moDe to operate.) .......................6

2.2.3 SimpliFieD inStallation (t-4) (thiS conFiguration DoeS not allow recirculation moDe to operate.) ..............7

2.3 CONNECTING THE DRAIN (HRV ONLY) .................................................................................................... 8

2.4 INSTALLING THE EXTERIOR HOODS .......................................................................................................9

2.5 CONNECTING THE DUCTS TO THE UNIT ................................................................................................. 9

2.5.1 DuctS connection .................................................................................................................................10

3. CONNECTIONS .................................................................................................................11

3.1 ELECTRICAL CONNECTION TO OPTIONAL MAIN WALL CONTROL .................................................... 11

3.1.1 electrical connection to DehumiDiStat or automatic optional main wall control ................................ 11

3.1.2 electrical connection to aDvanceD optional main wall control .......................................................... 11

3.2 ELECTRICAL CONNECTION TO OPTIONAL AUXILIARY WALL CONTROL ...........................................12

3.2.1 electrical connection to 20-40-60 optional auxiliary wall control ...................................................12

3.2.2 electrical connection to Dry contact optional auxiliary wall control (e.g. crank timer) .................12

3.3 CONNECTION TO THE CENTRAL FORCED-AIR SYSTEM .....................................................................13

3.3.1 unit operation uSing a Dry contact connection...................................................................................13

3.3.2 unit interconnection with central ForceD-air SyStem (r/c/g/gF) .......................................................13

3.3.3 Synchronization with central ForceD-air SyStem Function ...................................................................13

4. WIRING DIAGRAM ............................................................................................................14

5. NAVIGATION ON LCD SCREEN ....................................................................................... 15

5.1 LCD SCREEN ............................................................................................................................................16

5.2 UNIT FIRST BOOT .....................................................................................................................................16

5.3 SETTINGS MODIFICATION .......................................................................................................................16

5.3.1 proceDure to moDiFy min cFm Setting ....................................................................................................16

5.3.2 proceDure to moDiFy max cFm Setting ...................................................................................................16

5.3.3 proceDure to moDiFy optionS Setting...................................................................................................16

5.3.4 proceDure to moDiFy inDepenDent airFlowS Setting ..............................................................................16

5.4 FACTORY SETTINGS RESET ................................................................................................................... 17

6. USING THIS UNIT ..............................................................................................................17

6.1 YOUR VENTILATION SYSTEM ..................................................................................................................17

6.2 INTEGRATED CONTROL ..........................................................................................................................17

6.3 AHU MODE DISPLAY ................................................................................................................................17

7. SERVICE PARTS ................................................................................................................ 18

8. INSTALLER’S TROUBLESHOOTING ...............................................................................20

8.1 ELECTRONIC PROTECTION TO PREVENT ABNORMAL HIGH STATIC PRESSURE ............................22

9. MAINTENANCE .................................................................................................................23

9.1 QUARTERLY ..............................................................................................................................................23

9.2 ANNUAL (AT FALL) ....................................................................................................................................24

10. USER’S TROUBLESHOOTING .......................................................................................24

11. WARRANTY ......................................................................................................................25
