Domobar Junior 2B
user’s guide
2 3
Summary
1. Unpacking and Assembly
2. Water
3. Connect the machine
4. Start up
4.1. Start up: plug the machine
4.2. Start up: turn the machine ON
4.3. Start up: grouphead
4.4. Start up: steam boiler pressure gauge
4.5. Start up: brew pressure gauge
5. First use of machine
6. Coffee boiler temperature adjustment
7. Steam boiler pressurestat adjustment
8. Hints, Tips, and Tricks
8.1. Maximizing Steaming Power
8.2. Minimizing Temperature Variations During the Pull
8.3. Minimizing Mineral Buildup
9. Troubleshooting
9.1. The machine is not working
9.2. No water can be pumped
9.3. The Grouphead is not getting very warm
9.4. I can pump water, but the water is always cold
9.5. The Machine Stopped Suddenly in the Middle of a Pull
9.6. The Coffee Tastes Bad
9.7 Bitter coffee can come from:
9.8. Sour tastes can come from:
10. Cleaning and Maintenance
10.1. After Each Pull
10.2. After each stratching milk
10.3. After Each Session
10.4. Backflushing
10.5. Exterior Cleaning
10.6. Grouphead Gasket Replacement
10.7. Hot Water Wand and Steam Wand
10.8. Long Term Storage
Waste disposal
5
8
9
10
10
11
12
12
13
14
15
16
16
16
17
17
18
18
18
18
19
19
19
20
20
21
21
21
22
23
24
25
26
26
31
4 5
1. Unpacking and Assembly
CAUTION: Vibiemme Domobar espresso machines are quite heavy. The shipping weight is around 70
pounds! We recommend getting assistance whenever the machine has to be moved or relocated. Open the
box and carefully remove the machine. Setting the box on a carpeted surface or on a large, soft towel so that
the machine has its backside down makes it easier to slide it out of the box (as shown here, to the left).
CAUTION: The machine ships with the hot water valve closed and the steam valve open. DO NOT force
the valves. Moderate pressure is sufficient to open or close the valves. They do not have to be shut tight, or
“seated,” like a home faucet to seal properly.
Slip off the large plastic bag and remove the end of the power cord from the parts box. Slide the parts box
sideways to remove it from its shipping location.
Please inspect the machine upon unpacking to be sure it was not damaged during shipping. Report any
shipping damage immediately to the shipper as well as to your reseller/retailer.
WARNING: There are times when a machine will dribble water during shipping. If you notice that
the machine arrives wet or dripping, remove the machine as described in this section, but wait
24 hours to allow excess moisture to evaporate to alleviate any electrical danger or damage from
short circuits. If in doubt, open the case as described later in this manual to assist in drying as well
as to inspect for accumulated water in the machine.
You may notice that there is a rough area on the right side of the Grouphead where the chrome is
not quite as smooth and shiny as the rest of the Grouphead. This is from the production process
and is not a defect.
Stand the machine upright and remove the five pieces of tape- three holding the top Cup Warmer Tray
and two holding the Drip Tray Cover. Remove the Cup Warmer Tray and take off the protective
plastic wrap and the white, stick-on protective plastic on the tray itself. Clean any remaining adhesive or
bits of plastic from the warming tray with a cleaning product meant for stainless steel.
Inspect the area of the inner panel under the Cup Warmer Tray. There should be a small black plug
inserted in the panel. If not, it is possible that it fell into the machine during shipping. If the plug is not
visible, remove the six slotted screws (three on each side of the back panel) and slide the panel off to
the rear of the machine. It can help if you spread the front of the panel just enough get it to slide easily.
