Oldal 1/9
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have questions or need assistance, please call customer service at 855-944-3571.
User
Manual
WGen7500s
Portable Generator
2 | English
TABLE OF CONTENTS
Introduction ..................................................................................................................................................................................................2-3
Safety ............................................................................................................................................................................................................ 4-9
Electrical ........................................................................................................................................................................................................10
Components ..............................................................................................................................................................................................11-12
Assembly ..................................................................................................................................................................................................13-14
Operation ..................................................................................................................................................................................................15-20
Maintenance ..............................................................................................................................................................................................21-27
Troubleshooting ............................................................................................................................................................................................. 28
Schematics ....................................................................................................................................................................................................29
Service Hotline/Company Address .....................................................................................................................................................Back Page
INTRODUCTION
WARNING
Operating, servicing, and maintaining
this equipment can expose you to chemicals including engine
exhaust, carbon monoxide, phthalates, and lead, which are
known to the State of California to cause cancer and birth
defects or other reproductive harm. To minimize exposure,
avoid breathing exhaust, and wear gloves or wash hands fre-
quently when servicing this equipment. For more information
go to www.P65warnings.ca.gov.
DISCLAIMERS
All information, illustrations, and specifications in this manual
were in effect at the time of publishing. The illustrations used in
this manual are intended as representative reference views only.
We reserve the right to make any specification or design change
without notice.
ALL RIGHTS RESERVED
All rights reserved. No reproduction allowed in any form without
written permission from Westinghouse Outdoor Power Equipment.
DANGER
Read this manual before us-
ing or performing maintenance on this product. Fail-
ure to follow the instructions and safety precautions
in this manual can result in serious injury or death.
UPDATES
The latest User Manual for Westinghouse products can be found
under our support tab. wpowereq.com/pages/manuals
Or scan the following QR code with a smartphone camera to be
directed to the link.
PRODUCT REGISTRATION
For trouble-free warranty coverage, it is important to register the
Westinghouse product.
Register by:
l Completing and mailing the product registration card included
in the carton.
l Registering the product on-line at: wpow-
ereq.com/pages/warranty-registration
l Scanning the above QR code with the
smartphone camera to be directed to the
mobile registration link.
For The Records
Date of Purchase:
Model Number:
Serial Number:
Place of Purchase:
l Sending the following product information to:
Westinghouse Outdoor Power
Warranty registration
777 Manor Park Drive
Columbus, OH 43228
IMPORTANT: Keep the purchase receipt for trouble-free warranty
coverage.
English | 3
INTRODUCTION
SPECIFICATIONS
AC Voltage ..................................................................120V/240V
Power (Running) ............................................................... 7500W
Power (Peak) .................................................................... 9500W
AC Current ...................................................................... 60A/30A
Frequency ............................................................................60 Hz
Phase .................................................................................. Single
RPM ...................................................................................... 3600
Power Factor ............................................................................ 1.0
Insulation Class .......................................................................... H
Maximum Ambient Temperature ..............................104°F (40°C)
Fuel Type ................................ Unleaded gasoline (87–93 Octane)
Do not use E15 or E85 fuel in this product.
Fuel Capacity ...............................................6.6 gallons (25 liters)
Oil Capacity ............................................... 1.16 quarts (1.1 liters)
Oil Type .....................................................................SAE 10W-30
Spark Plug ............................................................................F7TC
Spark Plug Gap ......................... 0.024 – 0.032 in. (0.6 – 0.8 mm)
Valve Intake Clearance ...................................0.0031 – 0.0047 in.
(0.08 – 0.12 mm)
Valve Exhaust Clearance ................................0.0051 – 0.0067 in.
(0.13 – 0.17 mm)
AC Grounding System .........................................Bonded to frame
NOTICE
The effect of altitude on horsepower will be
greater if no carburetor modification is made. A decrease in
engine horsepower will decrease the power output of the
generator. Contact our service team to order altitude kits.
NOTICE
Thank you for choosing Westinghouse!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a prob-
lem with the Westinghouse purchase, call us at
1-855-944-3571 to speak with an agent.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
NOTICE
This product is designed and rated for con-
tinuous operation at ambient temperatures betweem 23°F
(– 5°C) and 104°F (40°C). If needed, this product can be op-
erated in extremely hot or extremely cold temperatures for
short periods. If the product is exposed to extreme tempera-
tures during storage, it should be brought back within the op-
timal temperature range before operation. This product must
always be operated outdoors in a well-ventilated area and far
away from doors, windows, and other vents.
Maximum wattage and current are subject to and limited
by such factors as fuel BTU content, ambient temperature,
altitude, engine conditions, etc. Maximum power decreases
about 3.5% for each 1,000 feet above sea level, and will also
decrease about 1% for each 10°F (6°C) above 60°F (16°C)
ambient temperature.
HAVE QUESTIONS?
Email us at service@wpowereq.com
or call 1-855-944-3571
