RM Series Wireless Microphone System Reference Manual
1
RM Series Wireless Microphone System
Reference Manual
Microphone Access Point
RM-WAP-16 RM-WAP-8
Wireless Microphone
RM-WOM RM-WDR RM-WGL RM-WGS
Microphone Charger
RM-WCH-8
Information............................................................................................................................................................................................... 1
INTRODUCTION....................................................................................................................................................................2
Available utility software .......................................................................................................................................................................... 2
Available manuals.................................................................................................................................................................................... 2
CONTROLS AND FUNCTIONS ............................................................................................................................................3
RM-WAP-16 RM-WAP-8 ......................................................................................................................................................................... 3
RM-WOM RM-WDR ................................................................................................................................................................................ 5
RM-WGL RM-WGS ................................................................................................................................................................................. 7
RM-WCH-8 .............................................................................................................................................................................................. 8
INSTALLATION AND SETUP .............................................................................................................................................10
AVAILABLE UTILITY SOFTWARE.....................................................................................................................................11
Starting up the Web GUI Device Manager ............................................................................................................................................ 11
Using the SITE SURVEY function ......................................................................................................................................................... 14
Using the AUTO SETUP function .......................................................................................................................................................... 17
APPENDIX ...........................................................................................................................................................................25
Block diagram ........................................................................................................................................................................................ 25
EXPLANATIONS .................................................................................................................................................................26
About DECT........................................................................................................................................................................................... 26
Understanding the [SITE SURVEY] window.......................................................................................................................................... 28
Increasing the number of microphones that can be used...................................................................................................................... 31
Updating the firmware............................................................................................................................................................................ 32
Initializing ............................................................................................................................................................................................... 32
MAIN SPECIFICATIONS .....................................................................................................................................................33
RM-WAP-16 RM-WAP-8 ....................................................................................................................................................................... 33
RM-WOM RM-WDR RM-WGL RM-WGS .............................................................................................................................................. 34
RM-WCH-8 ............................................................................................................................................................................................ 36
Information
• The illustrations and images shown in this manual are for instructional purposes only.
• The company names and product names in this manual are trademarks or registered trademarks of their respective companies.
• We are continuously improving the software for our products. The latest version can be downloaded from the Yamaha website.
CONTENTS
RM Series Wireless Microphone System Reference Manual
2
• This document is based on the latest specifications at the time of publication. The latest version can be downloaded from the Yamaha
website.
• Reproduction of this manual in whole or in part without permission is prohibited.
• In this manual, the microphone access point is referred to as “access point”, the wireless microphone is referred to as “microphone”,
and the microphone charger is referred to as “charger”.
Thank you for purchasing these Yamaha RM series wireless microphone system products.
These products, which include a wireless microphone, access point, battery, charger, etc., are part of the ADECIA wireless solution.
For correct and safe use of this unit, be sure to first read this manual carefully together with the Owner’s Manual included with each
product.
Available utility software
This utility software can be used to set up this unit according to its use and environment.
Available manuals
This describes the manuals related to this product.
Software and manuals related to this product can be downloaded from the following website.
Yamaha website (Downloads)
https://download.yamaha.com/
INTRODUCTION
Web GUI “RM-WAP Device Manager” This allows you to use a computer browser to configure and operate this unit.
RM Device Finder This is application software for controlling ADECIA devices on the network. It
detects the ADECIA devices on the network and displays the Device Manager
for each device.
ProVisionaire Design
This is Windows application software for designing and managing an entire
sound system made up of a combination of various devices.
ProVisionaire Control
This is Windows application software that allows you to remotely control
parameters for various devices from a single control panel.
ProVisionaire Touch
This is iPad application software that allows you to remotely control
parameters for various devices from a single control panel.
RM-WAP Owner’s Manual (included) This contains the precautions for using this unit safely as well as the
installation procedure.
RM-WOM Owner’s Manual (included)
RM-WCH Owner’s Manual (included)
RM-WBT Owner’s Manual (included)
RM Series Wireless Microphone System
Reference Manual (this manual/PDF)
This provides details on connecting and using this unit.
RM Series Wireless Microphone System
Web GUI Device Manager Operation Guide
This provides details on the Web GUI Device Manager, which allows you use
your computer to configure and operate this unit.
RM Series Remote Control Protocol
Specifications
This provides details on command information for acquiring and controlling
information about this unit from external devices.
ProVisionaire Design User Guide This provides details on using ProVisionaire Design.
ProVisionaire Control Setup Guide This provides details on using ProVisionaire Control.
RM Series Wireless Microphone System Reference Manual
3
RM-WAP-16 RM-WAP-8
[Front panel]
1 Power indicator
2 Status indicator
3 Reset button
NOTE: Use a fine-tipped object to press the Reset button.
CONTROLS AND FUNCTIONS
Condition Power indicator Unit status
LAN cable plugged into Dante/PoE port Lit green Operating
– Flashes red quickly System error occurring
Condition Status indicator Unit status
Pairing using Web GUI Flashes blue quickly Waiting for pairing/Pairing
Pairing using Web GUI
(After flashing blue quickly)
Flashes blue twice
Paired successfully
Pairing using Web GUI
(After flashing blue quickly)
Flashes red twice
Pairing failed
Identify icon in Web GUI clicked Flashes white Responding (to Identify function)
Updating firmware Flashes white quickly Firmware being updated
Updating firmware
(After flashing white quickly)
Flashes white twice
Firmware updated successfully
Updating firmware
(After flashing white quickly)
Flashes red twice
Firmware update failed
– Flashes red Transmission error occurring
– Flashes red quickly System error occurring
Condition Status indicator Unit status
Reset button long-pressed for 4 seconds to
less than 8 seconds, then released
Flashes blue twice per second
(during long-pressing/resetting)
Network-related settings
Waiting for resetting/Resetting
(Automatically restarts after reset)
Reset button long-pressed for 8 seconds to
less than 12 seconds, then released
Flashes blue three times per second
(during long-pressing/resetting)
All settings
Waiting for resetting/Resetting
(Automatically restarts after reset)
1 2 3
