Preparation - Uninstall Intel Stock Cooler

Installation of Alpine 11 Rev.2

CPU FAN

Clean the CPU carefully

Clean the CPU carefully. Remove the residue paste by paper tissue

. Remove the residue paste by paper tissue

carefully

carefully.

Clean the CPU carefully. Remove the residue paste by paper tissue

carefully.

Tissue

The Intel CPU cooler fastening mechanism requires the motherboard to bend. In order to do so, we strongly recommend you to install the

motherboard in the PC case first before assembling the Alpine 11 Rev.2.

The heatsink base is asymmetrical. If the cooler contacts with capacitors or other components around the CPU, rotate the cooler 90°. If it still does

not fit, turn again. Install the cooler at the position where it does not touch anything.

CPU FAN

Alpine 11 Rev.2

Installation Manual

Installation Manual: www.arctic.ac/fileadmin/alpine11r2/manual_en.pdf

Montageanleitung: www.arctic.ac/fileadmin/alpine11r2/manual_de.pdf

Guide d’installation: www.arctic.ac/fileadmin/alpine11r2/manual_fr.pdf

Manual de instalación: www.arctic.ac/fileadmin/alpine11r2/manual_es.pdf

Manual de Instalação: www.arctic.ac/fileadmin/alpine11r2/manual_pt.pdf

Installationsmanual: www.arctic.ac/fileadmin/alpine11r2/manual_se.pdf

Instala ní p íru ka: www.arctic.ac/fileadmin/alpine11r2/manual_cz.pdfčřč

Telepítési kézikönyv: www.arctic.ac/fileadmin/alpine11r2/manual_hu.pdf

Instrukcja monta u: www.arctic.ac/fileadmin/alpine11r2/manual_pl.pdfż

Installatiehandleiding: www.arctic.ac/fileadmin/alpine11r2/manual_nl.pdf

Руководство пользователя: www.arctic.ac/fileadmin/alpine11r2/manual_ru.pdf

Manuale di installazione: www.arctic.ac/fileadmin/alpine11r2/manual_it.pdf

Warranty

This ARCTIC product includes a six-year limited warranty. Please visit warranty.arctic.ac for further details.

The thermal compound is already pre-applied to the heatsink. If the cooler has to be installed a second time, we highly recommend using the MX- 4 from ARCTIC. Only this compound guarantees

optimal performance in combination with the surface of our heatsinks.

Thermal Compound

No part of this manual including the products described in it, may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form or by any means, except documentation

kept by the purchaser for backup purpose, without the express written permission of ARCTIC (HK) Ltd. In no event shall ARCTIC (HK) Ltd. and its directors or employees be liable for any indirect damages,

incidental or consequential damages arising from any defect or error in this manual or product.
