Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Thank you for purchasing ARTUSI
and welcome to the ARTUSI Family.
This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance
has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
We present detailed information on each of the features your ARTUSI appliance consists of. Once you have read
this section you will be able to choose the most appropriate settings for your appliance when cooking different
types of food.
We ask you to read the instructions in this booklet very carefully as this will allow you to get the best results from
using your appliance. KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
TO REGISTER YOUR PRODUCT WITH ARTUSI, PLEASE FILL OUT THE WARRANTY CARD AT THE END OF
THIS BOOKLET AND POST IT TO: REPLY PAID 83617
LEICHHARDT NSW 2040
Dear Artusi Customer, please read this user manual carefully before using the product and, keep it permanently at
your disposal.
Note: This user manual is prepared for more than one model. Some of the features specified in this Manual may not
be available on your appliance.
All our appliances are only for domestic use, not for commercial use. Products marked with (*) are optional.
“THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE REGULA TIONS FORCE AND ONLY USED
IN A WELL VENTILATED SPACE. READ THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE”
“Conforms with the WEEE Regulations.”
Model Power Supply Po
AC 220-240V
50-60Hz 1200W
(145m
Cod 0070303178：
V20190830
Good Bad
(recessed base) (convex base) (u
Bad B
Technical Data
Please read the instruction manual carefully before operating your new hob.
Dear Owner: Thank you for purchasing our cooktop designed to give you many years of cooking
pleasure. Before using your new appliance please read the user manual carefully and keep it in a safe
place for future reference.
THIS APPLIANCE MUST ONLY BE INSTALLED BY A QUALIFIED PERSON USING THE
INSTRUCTIONS PROVIDED. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
IMPROPER INSTALLATION THAT MAY HARM PERSONS AND ANIMALS OR CAUSE DAMAGE
TO PROPERTY. THE APPLIANCE MUST ONLY BE USED FOR THE PURPOSE FOR WHICH IT
WAS DESIGNED. ANY OTHER USE (e.g. HEATING ROOMS) IS CONSIDERED TO BE IMPROPER
AND MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE RESULTING FROM
IMPROPER AND/ OR IRRESPONSIBLE USE.
Safety cut-off
•When one or more of the cooking zones are a
period of time. The length of time depends on
time limits for each power level.
•When more than one zone is operating and o
that has reached its safety cut-off point will sw
Timer
•Your hob has a timer which you can set (from
end of the countdown period, a buzzer will sou
•Select the cooking zone (fig. 2) and heat leve
Press the timer button (fig. 5), and then use th
time.
• Each time the timer up or down button is pre
in 1 minute increments.
Locking the ceramic hob
To lock the ceramic hob, press the safety lock
on. With the safety lock activated, all buttons o
the ON/OFF button. To disable the safety lock
Then adjust the heat level of any zone on the
When the hob is in the lock mode, all the contr
always turn the induction hob off with the ON/O
Time limit (hours)
Power level 1
6
2
6
Using the Touch Controls
•The controls respond to touch, so you don’t need to apply any pressure
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or
a cloth) covering them. Even a thin film of water may make the controls difficult to
operate.
fig.1
fig.3
Touch control
• All operations are performed by means of the touch controls on the control panel.
• Each touch control has a corresponding visual display (indicator light).
• You will hear a beep each time a touch is registered.
Switching on the ceramic hob
• Press the ON/OFF button (fig. 1) to switch on the appliance.
• The hob will beep once and all cooking zone indicators will light up briefly indicating
that the hob has entered stand-by mode.
Note: Make the next step within one minute otherwise the hob will automatically shut down.
Switching on a cooking zone and setting a power level
• Press the cooking zone select button (fig. 2) for the zone you want to use.
• Select the heat level required (1-9) by using the up and down buttons (fig. 3). By holding
down either of these buttons, the value on the heat level display will adjust up or down.
Note: when the power level displayed is 0, press the down button and the power will set to 9
Switching off the ceramic hob
1. Press the ON/OFF button, the hob will switch off. It is possible to turn the hob off at any
time by pressing the ON/OFF button.
2. Press the up or down buttons to 0, then hob will switch off.
After a zone is switched off, the corresponding heat level display will show a flashing letter “H”
(Hot). This means that the temperature of the zone is above 60°C and is still high enough to
cause injury.
When the temperature of the zone falls below 60°C the letter “H” will go out. It is still
possible to burn yourself on a hob zone, even when its temperature has dropped below 60°C.
IMPORTANT: The residual heat indicator will disappear if the power supply to the product is cut.
Operation of the hob heating zones
To save energy and to have a longer life of the ceramic hob, we advise using pots and pans with flat
bottoms and with a diameter not less than the diameter of the heating zones. Care must be taken that fluids
do not spill on the ceramic hob. Never leave the heating zones on without pans or with empty pans on
them. Never use the heating zones to warm plates. Switch on the heating zones after having put the pans
on them. CAUTION: when switched off the heating zones remain hot to warm for some time so do not
touch. Switch off the heating zones before removing the pans.
Utensils
Use pans with flat bottoms. Uneven or thin bot
Use pans slightly larger than the cooking zone
Do not use oversized pans. More than 50mm
fine cracks in the enamel hob that will trap dirt
Use only dry utensils. Do not place wet or stea
Do not use pots and pans that are unsteady a
Do not operate the cooktop without pots or pa
WARNING: Unattended cooki
and may result in a fire. In the
and then cover the flame with
extinguish a fire with water.
CAUTION: Never leave any co
overflows, burnt food and/or f
Danger of fire: Do not store it
16.Do not touch the built-in ceramic hob with wet hands or while standing in water with bare feet.
17.Do not operate the built-in electric hob when you are bare footed.
18.Always disconnect the power supply before you do any maintenance and cleaning.
When the built-in ceramic hob is working, the t
temperatures become higher, so do not touch
19.The built-in ceramic hob must be built into a
20.NOTE: Some smoke may occur when the h
burn off excess sealants etc. used in the manu
fig.2
Heating area
(Φ145mm)
Heating area
(Φ145mm)
Heating area
(Φ180mm)
Heating area
(Φ180mm)
CACC1A
