Installation Guide

AT-VCC-RS232-KIT

1

IP to RS-232 Command Converter for Velocity Control

System

AT-VCC-RS232-KIT

The Atlona AT-VCC-RS232-KIT is an accessory for the Atlona Velocity™ Control System that

provides conversion between IP and RS-232 control commands. This Velocity Control Converter

is very compact and can be placed anywhere a device requires control and is not IP-capable.

The VCC-RS232-KIT is remotely powered through Power over Ethernet (PoE), or locally from a

USB power source. The primary unit installs onto any surface via a convenient mounting dock. A

simple “click” locks it into place for a secure, reliable installation. An RS-232 gender changer is

included.

1 x AT-VCC

1 x AT-VCC-RS232

Package Contents

Operating Notes

•The AT-VCC-RS232-KIT is PoE, to power the unit, simply plug it into a PoE compatible

network switch. If the network switch is not PoE capable, a PoE injector (purchased separately)

or USB can be used.

•All devices (AT-VCC, Velocity, AT-VTP, switchers, etc) should be set to static IPs or the

DHCP IP address reserved for each individual device.

IMPORTANT: Velocity Gateway (AT-VGW-HW) must be set up before the AT-VCC-RS232-

KIT is fully functional.
