OWNER’S MANUAL
STREAMER / DAC
AMPLIFIER
SDA300 SIGNATURE
OWNER’S MANUAL ~ STREAMER · DAC · AMPLI
ATOLL ELECTRONIQUE
Page 2
– An SDA300 Signature Streamer
Dac Amplifier .
– A power lead.
– A RCA cord.
– A remote control.
– Two antennas.
– This manual with the warranty
certificate.
• Do not make any connections when your device is turned on.
• Install your appliance in a dry, well-ventilated place away from any source of heat.
• Do not put anything on your Streamer.
• Avoid any short circuits.
• Never connect two speakers in parallel to the same output.
SAFETY INSTRUCTIONS
• It is recommended to choose good quality cords to connect this appliance to the other
devices. Feel free to take advice from your specialist dealer.
USER ADVICES
YOU WILL FIND ENCLOSED
INDEX
1.– General information...........................................................
2.– Connections......................................................................
3.– ATOLL remote control.........................................................
4.– Connecting setup...............................................................
5.– Preamp. / BY-PASS functions...............................................
6.– Uses................................................................................
Getting started.............................................................
Playlists........................................................................
Playqueue....................................................................
Internet radio................................................................
Front and rear USB.......................................................
Media server.................................................................
Streaming services.........................................................
Roon and Audirvana.....................................................
Bluetooth®..................................................................
7.– Troubleshooting table.........................................................
p.3
p.4
p.5
p.6
p.7
p.7
p.7
p.10
p.10
p.10
p.10
p.11
p.11
p.11
p.11
p.12
You have just purchased a product with exceptional audiophile performance. Your
confidence in our products is greatly appreciated. To get the most out of your streamer,
make sure to read this manual carefully.
SDA300 Sig
ATOLL ELECTRONIQUE
Page 3
1.- GENERAL INFORMATION
GENERAL INFORMATION AND ADVICES
CLEANING
WARRANTY CONDITIONS
Before any cleaning, switch off your appliance. Use a soft and dry rag to clean up the appliance. Never use
acetone, white-spirit, ammoniac, or any kind of product containing abrasive agents. Never try to clean up
inside the appliance.
The guarantee is two years period from the date of purchase. We recommend you ask your dealer to fill the
guarantee and to conserve it with your invoice. The guarantee is only available for the appliance which has
been used correctly regarding this owner’s manual.
(*) The SDA300 Sig includes MQA Core Decoder, which unfolds the MQA file once to deliver better than CD-quality. The first unfold
recovers all the direct music-related information. Output is 88,2 kHz or 96 kHz. ‘MQA’ or ‘MQA Studio’ indicates that the product
is decoding and playing an MQA stream or file, and denotes provenance to ensure that the sound is identical to that of the source
material. ‘MQA Studio’ indicates it is playing an MQA Studio file, which has either been approved in the studio by the artist/producer or
has been verified by the copyright owner. MQA and the Sound Wave Device are registered trade marks of MQA Limited © 2016.
– AAC (24-96 kHz 16 bits).
– AAC+ v1/HE-AAC.
– FLAC (44,1-96 kHz 16/24 bits).
– FLAC 192 kHz/16-24 bits; available on USB-A
inputs, RJ45 link and WIFI.
– MP3 (8-48 kHz 16 bits).
– WAV (22-96 kHz 16/24 bits).
– AIFF & ALAC.
– DSD64 & DSD128.
– MQA (Master Quality Authenticated)
(*)
.
Power supply:
Wrms/channel/8 Ω:
Wrms/channel/4 Ω:
Audio outputs:
Audio inputs:
Total of capacitors:
Dynamic:
Switch OFF consumption:
Standby power consumption (preheating):
ON consumption:
Input Impedance:
Maximum input level:
Distortion at 1 kHz:
Bandwidth:
Rising time:
Sensibility:
Signal/Noise ratio:
Digital/analog converter:
Dimensions:
Weight:
2×440 +2×4,5 + 3,2 VA
2×150 W
2×260 W
2 Speakers outputs
1 Pre-out output
1 Coaxial S/PDIF output
1 Optical Toslink S/PDIF output
2 Analog inputs – 2 coaxial S/PDIF (PCM1792 24 bits/192 kHz)
2 Optical Toslink S/PDIF inputs (PCM1792 24 bits/192 kHz)
2 USB-A inputs: 1 front, 1 rear
65 800 µF
129 dB
0 W
30 W
34 W - 700 W
220 kΩ
3,5 Vrms
0,05% / (10 W)
5 Hz - 150 kHz
1,3 µs
350 mV
129 dB
BURR-BROWN PCM1792 24 bits/192 kHz
440×365×103mm
19 Kg
TECHNICAL DATA
Your ATOLL Streamer is DLNA and UPnP compatible, allowing it to work in a network with other devices. Take
the time to carefully read the getting started section of this user guide before turning on your device.
To use your device as easily as possible, download the ATOLL Signature (2) App from the Apple Store
or the Google Play store.
ACCEPTED FORMATS
