MetraOnline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 11/11/20 INST99-7397B
INSTALLATION INSTRUCTIONS
99-7397B
Attention!Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Painted scratch resistant matte black
• Retains factory steering wheel controls (pre-wired in included harnessing)
• Radio harness included with connections to retain factory camera
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Panel clip legs • D) Pocket • E) Panel clips (2) • F) #6 x 3/8” Phillips screws (4)
• G) #8 x 3/8” Phillips screws (8) • H) Steering wheel control interface (not shown) • I) 6 volt factory camera adapter (not shown)
• J) Radio wire harness (not shown) • K) Antenna adapter (not shown)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench • T-25 Torx driver • Cutting tool
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation ....................................................2-3
Kit Assembly
–ISO DIN radio provision with pocket ..................4
–ISO DDIN radio provision .....................................4
AXXESS Interface installation ............................5-11
Final Assembly ......................................................11
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: Included in kit
Antenna Adapter: Included in kit
SWC Interface: Included in kit
6v Camera Adapter: Included in kit
ABC
G
DE
F
Kia Soul(Non-NAV)2020
Visit for more detailed information about the product and up-to-date vehicle MetraOnline.com
specific applications
