Metra. The World’s Best Kits.

®

MetraOnline.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 12/30/21 INST99-7821B

INSTALLATION INSTRUCTIONS

99-7821B

Attention!With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

NOTE: Refer to the instructions included with

the aftermarket radio.

KIT FEATURES

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Pocket • D) #8 x 3/8" Phillips screws (4)• E) Plastic panel clips (8)

• F) Axxess wiring harness and interface (not shown) • G) Antenna adapter (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

TABLE OF CONTENTS

Dash Disassembly

..................................................2

Kit Preparation .......................................................3

Kit Assembly

–ISO DIN radio provision with pocket ..................4

–ISO DDIN radio provision .....................................4

Axxess Interface Installation ............................5-14

Final Assembly ......................................................15

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included in kit

Antenna Adapter: Included in kit

ABCDE

Honda Civic (excluding LX models) 2016-2021

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

specific applications. Note: Additional parts required to retain factory amplifier.

NOTE:TYPE R AND SI VEHICLES WILL NOT RETAIN THE REV MATCHING FEATURES.

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Painted matte black

• Touchscreen display for climate

and personalization features

• Retains the factory backup camera

and LaneWatch camera

• Retains audio controls on the

steering wheel

• Provides NAV outputs (parking

brake, reverse, speed sense)

Visit MetraOnline.com for audio/video and steering wheel control

interface options.

Note: Additional purchase of AXSP-HN is required to retain factory amplifier.

Identifiable when equipped with factory sub-woofer or center channel speakers.
