METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
Installation Instructions for AX-ADXSVI-AU1
REV. 9/26/2014 INSTAX-ADXSVI-AU1
(continued on next page)
AX-ADXSVI-AU1
Audi CAN interface 2006-2013
Caution: Metra recommends disconnecting the negative battery terminal before
beginning any installation. All accessories, switches, and especially air bag indicator
lights must be plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
AUDI
A3* 2006-2013
A4/RS 4/S4 w/ NAV 2005-2008
A4/RS 4/S4 2007-2008
A4/RS 4/S4* 2006
TT 2008-2013
*Note: Only for models with either a
Symphony Plus or NAV radio.
APPLICATIONS
FEATURES
Note: This harness must be used in conjunction with the AX-ADXSVI.
• Providesaccessory(12-volt10-amp)
• RetainsR.A.P.(retainedaccessorypower)
• ProvidesNAVoutputs(parkingbrake,reverse,andspeedsense)
• PrewiredASWC-1harness(ASWC-1soldseparately)
• Retainsbalanceandfade
• Micro“B”USBupdatable
Connections to be made
From the XSVI-AU1 harness to the aftermarket radio
(a) From the 12-pin harness:
• Connectthe wiretotheaccessorywire.Red
• Connectthe wiretotheilluminationwire,iftheaftermarketradiohasOrange
noilluminationwire,tapeoffthe wire.Orange
• Connectthe wiretotheampturnonwire(thiswiremustbeBlue/White
connectedtohearsoundfromthefactoryamplifier).
There is a wire on the 40-pin harness to connect as well.Note: Blue
Thefollowingwiresareforaftermarketmultimedia/navigationradiosthatprovide
thesewires(ifnotrequired,tapethemoffanddisregardthem):
• Connectthe wiretotheparkingbrakewire(ifapplicable).Light Green
• Connectthe wiretothereversewire(ifapplicable).Green/Purple
• The wirewillnotbeused,tapeitoffanddisregardit.Blue/Pink
Note: This wire will be on the 40-pin harness instead.
(b) From the 40-pin harness:
• Connectthe and wirestothegroundwire.Black Black/White
• ConnecttheYellow wiretothebatterywire.
• Connectthe wiretotheampturnonwire(thiswiremustbeconnectedBlue
tohearsoundfromthefactoryamplifier).
Thefollowingwireisforanaftermarketmultimedia/navigationradiothat
providesthiswire,ifnotrequired,tapeitoffanddisregardit:
• Connectthe wiretothespeedsensewire(V.S.S.),ifapplicable.Blue/Pink
INTERFACE COMPONENTS
•XSVI-AU1harness
TOOLS REQUIRED
•Cuttingtool•Tape•Crimpingtool
•Connectors(i.e.butt-connectors,bellcaps,etc.)
AX-ADXSVI-AU1
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better t omorrow.
Metra recommends MECP
certified technicians
IMPORTANT WARNING
Thisproductincludesinstructionsforinstallationwhichmustbecarefullyfollowed.The
instructionsarewordedinsuchamannertoassumethattheinstalleriscapableof
completingthesetypeofelectronicinstallations.Ifyouareunclearastowhatyouare
instructedtodoorbelievethatyoudonotunderstandtheinstructionssoastoproperly
andsafelycompletetheinstallationyou should consult a technician who does have this
knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described
could cause harm to the vehicle or to safety systems on the vehicle. Interference with
certain safety systems could cause harm to persons as well. If you have any questions
in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
For non-BOSE systems:
• Disregardthe RCA,itwillnotbeusedinthisapplication. White
• Disregardthe RCA,itwillnotbeusedinthisapplication.Gray
• Connectthe RCAtotheleftrearRCAoutput.Green
• Connectthe RCAtotherightrearRCAoutput.Purple
• Connectthe wiretotheleftfrontpositivespeakeroutput.White
• Connectthe wiretotheleftfrontnegativespeakeroutput.White/Black
• Connectthe wiretotherightfrontpositivespeakeroutput.Gray
• Connectthe wiretotherightfrontnegativespeakeroutput.Gray/Black
Tapeoffanddisregardthefollowingwires,theywillnotbeusedin 
thisapplication:
• The wires.Green,Green/Black,Purple,Purple/Black
For BOSE systems:
• Connectthe RCAtotheleftfrontRCAoutput.White
• Connectthe RCAtotherightfrontRCAoutputGray
• Connectthe RCAtotheleftrearRCAoutput.Green
• Connectthe RCAtotherightrearRCAoutputPurple
Tapeoffanddisregardthefollowingwires,theywillnotbeusedin 
thisapplication:
• TheGreen,Green/Black,Purple,Purple/Black,White,White/Black,
Gray,and wires.Gray/Black
Note: It is highly recommended that the radio being used has 2 sets
of RCA outputs to retain balance and fade; 3 sets if a sub-woofer amplifier
will be added.
(c) From the 12-pin harness (ASWC-1 pre-wired harness):
• ThisharnessistobeusedinconjunctionwiththeoptionalASWC-1(not
included)toretainsteeringwheelcontrols.IftheASWC-1isnotbeing
used,disregardthisharness.Ifitwillbeused,pleaserefertotheASWC-1
instructionsforradioconnectionsandprogramming.
Note: Disregard the harness that comes with the ASWC-1.
Installing the AX-ADXSVI-AU1
• Connectthe12-pinharnessintotheAX-ADXSVIinterface(soldseparately).
• Connectthe40-pinharnessintothevehicle.
• Withallconnectionscompleted,reconnectthenegativebatteryterminal.
• Initializetheinterfacebyturningtheignitiononfor30seconds,thenturnthe
ignitionbackoff,thenbackonagain.
Troubleshooting
• IfthevehiclehasenginenoiseafterinstallingtheAX-ADXSVI-AU1,useAxxess
partnumberAX-AGL610,qty.(2).
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
Installation Instructions for AX-ADXSVI-AU1
REV. 9/26/2014 INSTAX-ADXSVI-AU1
(continúa en la página)
AX-ADXSVI-AU1
Audi CAN interfase 2006-2013
Precaución: Metra recomienda desconectar el terminal negativo de la batería antes de
comenzar cualquier instalación. Todos los accesorios, interruptores y, especialmente,
las luces indicadoras de airbag deben estar enchufados antes de volver a conectar la
batería o comenzar el ciclo de ignición.
*Note: Remítase a las instrucciones incluidas con el radio de postventa.
AUDI
A3* 2006-2013
A4/RS 4/S4 w/ NAV 2005-2008
A4/RS 4/S4 2007-2008
A4/RS 4/S4* 2006
TT 2008-2013
*Note: Only for models with either a
Symphony Plus or NAV radio.
APLICACIONES
CARACTERÍSTICAS
Nota: Este arnés debe utilizarse en conjunto con el AX-ADXSVI.
• Proporcionaaccesorio(12voltios10amperes)
• RetieneR.A.P.(corrientedeaccesorioretenida)
• ProporcionasalidasdeNAV(frenodemano,reversaysensor
 develocidad)
• ArnésASWC-1precableado(elASWC-1sevendeporseparado)
• Retieneelbalanceylaintensidad
• Actualizablepormicro“B”USB
Conexiones que se deben hacer
Del arnés XSVI-AU1 al radio de mercado secundario
(a) Desde el arnés de 12 pins:
• Conecteelcable conelcabledeaccesorios.rojo
• Conecteelcable conelcabledeiluminaciónsielradiodemercadoanaranjado
secundarionotienecabledeiluminación,encínteloalcableanaranjado.
• Conecteelcable alcabledeencendidodelamplificador(esteazul/blanco
cabledebeestarconectadoparaescucharsonidodelamplificadordefábrica).
Hay un cable azul en el arnés de 40 pins que también debe conectar.Nota:
Lossiguientescablessonpararadiosdemercadosecundarioconmultimedios/
navegaciónquetienenestoscables(sinoserequieren,encínteloseignórelos):
• Conecteelcable alcabledefrenodemano(siaplica).verde claro
• Conecteelcable alcabledereversa(siaplica). verde/púrpura
• Elcable noseutilizará,encínteloeignórelo.azul/rosa
Nota: Este cable se encontrará en el arnés de 40 pins.
(b) Desde el arnés de 40 pins:
• Conecteelcable yelcablenegro/blancoconelcabledetierra.negro
• Conecteelcable conelcabledelabatería.amarillo
• Conecteelcable alcabledeencendidodelamplificador(estecabledebeazul
estarconectadoparaescucharsonidodelamplificadordefábrica).
Elsiguientecableesparaunradiodemercadosecundarioconmultimedios/
navegaciónquetieneestecable;sinoserequiere,encínteloeignórelo:
• Conecteelcable alcabledelsensordevelocidad(V.S.S),siaplica.azul/rosa
COMPONENTES DE LA INTERFASE
•ArnésXSVI-AU1
HERRAMIENTAS REQUERIDAS
•Cortador•Cinta•Pelacables
•Conectores(ejemplo:conectoresdeextremo,decampana,etc.)
